Corrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage Tanks
Corrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage Tanks
Corrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage Tanks
Corrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage Tanks
Corrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage Tanks
Corrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage Tanks
Specifications
Brand Name :
CLINGSEAL
Model Number :
CS1080T
Certification :
ISO,SGS
Place of Origin :
CHINA
MOQ :
500KGS
Price :
USD 2.15-3.0 PER KG
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100Tons per month
Delivery Time :
1-4 weeks
Packaging Details :
pallets or wooden case
Grade :
Industrial Grade
Type :
Flexible Sheet,Composite Sheet,Reinforced Sheet
Application :
Sealing for high temperature and high pressure environments
C content (%) :
99.9%,99%
Color :
Black
Material :
Graphite
Density :
1.5 g/cm3
Thickness :
1.0mm
Hardness :
80 Shore A
Product name :
Graphite sheet
Shape :
can be customized
Sample :
Availble
Width :
≤1500 mm
Recovery (%) :
≥35
Reinforcement :
Metal mesh
Recovery :
15%
Temperature Resistance :
up to 500°C
Flexural Strength :
25MPa
Tensile Strength :
15MPa
Chemical Resistance :
resistant to most chemicals
Pressure Resistance :
up to 200 bar
Surface Finish :
Smooth
Compressibility :
40%
Description

Corrosion-Resistant Gasket Sheets for Chemical Processing and Storage Tanks

Looking for top-notch corrosion-resistant gasket sheets for your chemical processing and storage tanks? You've come to the right place! Our graphite gasket sheets, available in thicknesses ranging from 1.0 to 3mm, are designed to meet the most demanding industrial requirements.
Product Details
Our graphite gasket sheets are crafted with precision. They consist of two sides of pure flexible graphite sheet, sandwiching a 0.2 - 0.25mm perforated metal insert. The metal can be 0.2 - 0.25mm carbon steel (also known as tinplate), or options like ss201, 304, 316. You can choose from graphite with carbon contents of 95%, 97%, 98%, or 99%. This unique construction makes them ideal for use in high temperature and high pressure environments, such as steam cycling or exhaust applications within chemical processing and storage tank systems.

Corrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage Tanks

Product Features
  • Exceptional adaptability and durability, ensuring long - lasting performance.
  • Superior sealing capabilities, with no risk of delamination and high yield.
  • An economical choice for sealing gaskets, especially in exhaust and manifold applications.
  • Excellent oil - resistance, making it suitable for a wide range of chemical - related applications.
  • High resistance to both high temperature and pressure, perfect for the harsh conditions in chemical processing and storage tanks.
Product Sizes
  • Thickness: 1.0 - 6.0mm. For thicker options, we offer the 3 + 2 type (where the product section from top to bottom is Paper - Metal - Paper - Metal - Paper) and use multi - paper bonding technology.
  • Standard sizes include 500500mm, 5001000mm, 5001500mm, 10001000mm, 1000*1500mm. However, we also provide custom sizing to meet your specific needs.
Product Applications
These corrosion - resistant gasket sheets are highly suitable for oil sealing and gasket applications, particularly as cylinder head gaskets in chemical processing and storage tank machinery.
If you can't find the exact product you need or require a bespoke material for your chemical processing and storage tank projects, don't hesitate to contact us. Unsure which material is best for your application? Consult our gasket material selector or our guide to rubbers. Purchase your corrosion - resistant graphite gasket sheets for chemical processing and storage tanks from us today and experience the difference in quality and performance.



Physical Property:

Item Data
Tensile Strength (MPa,min.) ≥30
Compressibility (%,) 10-20
Recovery (%) ≥35
150ºC, At IRM 903# for 5hours Thickness Increase(%) ≤10
Weight Increase(%) ≤10
21ºC~30ºC, At B Fuel for 5hours Thickness Increase(%) ≤10
Weight Increase(%) ≤10
Thickness Deviation(mm) 0.05


Product Technical Details
As a general rule, graphite is:
• Good for use with steam
• Good ozone resistance
• Good with natural gas

Customer Service

We are happy to answer any questions that you might have about this product. Please contact us for more information.

Product Shows

Corrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage TanksCorrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage TanksCorrosion Resistant Gasket Graphite Sheet For Chemical Processing And Storage Tanks
