LUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight Spaces
LUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight Spaces
LUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight Spaces
LUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight Spaces
LUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight Spaces
LUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight Spaces
Specifications
Brand Name :
China
Model Number :
1.7 Ton
Certification :
CE, ISO9001, ISO14001, Special Equipment Manufacturing License / CE、ISO9001、ISO14001
Place of Origin :
China
MOQ :
1 unit (customizable according to user needs )
Price :
5500-9000USD
Payment Terms :
Western Union,T/T,D/P,D/A,L/C
Supply Ability :
50 Units 30 days
Delivery Time :
30-45 days (in stock for conventional models, customized models need to be negotiated separately
Packaging Details :
Nude packaging / Frame packaging (for sea transportation, to avoid damage during transportation
Description
1. Core Specifications
Parameter Details
Model LX-ME2 (1.7 Ton / 17 Series)
Brand LUXIN (Shandong)
Type Mini Crawler Excavator
Operating Weight 1,700 kg (1.7 tons)
Bucket Capacity (Standard) 0.04 m³
Engine Type Single-cylinder / Twin-cylinder diesel engine (optional: Coms, Kubota, EPA/Euro V compliant)
Rated Power 12.5 kW / 16.8 HP
Max Digging Depth 1,900 mm (1.9 m)
Max Digging Reach 3,000 mm (3.0 m)
Max Digging Height 2,500 mm (2.5 m)
Max Dumping Height 1,800 mm (1.8 m)
Swing Angle 360° continuous rotation
Track Width (Rubber) 230 mm
Overall Width (Tracks Retracted) 980 mm
Overall Width (Tracks Extended) 1,100 mm
Ground Clearance 150 mm
Gradeability 30°
Travel Speed (Low/High) 1.2 / 2.0 km/h
Bucket Digging Force 12 kN
Arm Digging Force 8 kN
2. Hydraulic & Control System
Parameter Details
Hydraulic Pump Type Gear pump
Main System Pressure 16 MPa
Control Valve Multi-way manual pilot control
Auxiliary Hydraulics Standard for breaker/auger attachments
Control Pattern ISO standard (left-hand swing/boom)
Pilot Joysticks Ergonomic design with adjustable sensitivity
3. Chassis & Structure
Parameter Details
Undercarriage Heavy-duty steel frame with rubber tracks
Track Type 230mm rubber tracks (wear-resistant, low ground pressure)
Slew Bearing Internal gear type with grease lubrication
Dozer Blade Standard 1000mm width for backfilling and grading
Boom & Arm Material High-strength Q345 steel, robotic welded
Canopy/Roll Bar ROPS-certified open canopy with sunshade
4. Standard & Optional Attachments
  • Standard: 0.04m³ digging bucket, dozer blade, operator seat with safety belt
  • Optional: Hydraulic breaker, auger drill, grapple, thumb, ripper, quick coupler
5. Operational Features
  • Ultra-compact design for narrow access (980mm retracted width, fits through standard doorways)
  • Zero tail swing for safe operation in tight spaces
  • Low ground pressure (0.035 MPa) for working on lawns, driveways, and soft ground
  • Simple maintenance with easily accessible engine and hydraulic components
  • Quiet operation (≤ 85 dB) for residential and urban job sites
6. Applications
  • Landscaping and garden maintenance
  • Residential construction (foundations, trenching)
  • Demolition and site clearing
  • Agriculture (orchard work, farm drainage)
  • Utility installation (pipes, cables)
  • Rental and small-scale contracting
7. Additional Info
  • Warranty: 1-year or 1000 working hours (whichever comes first)
  • Delivery: FOB Qingdao port, 7-15 days lead time
  • Certifications: CE, ISO, EPA Tier 4 (optional)
  • Color: Customizable (yellow as standard)
  • After-sales: Spare parts supply, video technical support, on-site service available
  • LUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight SpacesLUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight SpacesLUXIN LX-ME2 1.7 Ton Mini Crawler Excavator with EPA/Euro V Engine and Zero Tail Swing for Tight Spaces
