4X4 Fused PM Fiber Splitter Module
4X4 Fused PM Fiber Splitter Module
4X4 Fused PM Fiber Splitter Module
4X4 Fused PM Fiber Splitter Module
4X4 Fused PM Fiber Splitter Module
4X4 Fused PM Fiber Splitter Module
4X4 Fused PM Fiber Splitter Module
4X4 Fused PM Fiber Splitter Module
Specifications
Place of Origin :
Guangdong , China
Brand Name :
Gracyfiber
Certification :
ISO9001 , ROHS
Delivery Time :
5-8 work days
Payment Terms :
L/C,T/T
Supply Ability :
100,000 pieces per month
MOQ :
1pieces
Coupling Ratio :
25:25:25:25
Center Wavelength :
1550 nm
Operating Bandwidth :
±15 nm
Max Excess Loss :
1.2 dB
Insertion Loss :
7.5 dB
Max Optical Power :
300 mW
Description
4X4 Fused PM Fiber Splitter Module


Features
  • Wavelength 532 - 2100nm available
  • Low Insertion Loss
  • High Stability & Reliability
Applications
  • Coherent Communication
  • Power Monitor
  • Fiber Sensor
Specifications
Parameter Unit Value
Coupling Ratio % 25:25:25:25
Type - 4x4
Center Wavelength nm 1550
Operating Bandwidth nm ±15
Max. Excess Loss dB 1.2
Insertion Loss
7.5
Min. Extinction Ratio dB 20
Min. Directivity dB 50
Max. Return Loss dB 50
Max. Optical Power (CW) mW 300
Fiber Type - PM1550 fiber, 900mm Loose Tube
Package Dimensions mm 100*80*10
Operating Temperature ℃ -5~+75
Storage Temperature ℃ -40~+85

With connectors, the handling power is 50mW only, IL is 0.3dB higher, RL is 5dB lower, and ER is 2dB lower.

Connector key is aligned to slow axis.

Package Dimensions
4X4 Fused PM Fiber Splitter Module
Ordering Information

PMFUC-①①①①-②②-③③③-④-⑤-⑥-⑦-⑧

①①①① - Wavelength:
1550=1550nm, SSSS=Specified
②② - Port Type:
44=4x4
③③③ - Fiber Type:
001=PM1550 fiber
④ - Package Dimensions:
0=108*80*10, S=Specified
⑤ - Pigtail Type:
0=bare fiber, 1=900μm loose tube 2=2.0mm loose tube 3=3.0mm loose tube
⑥ - Fiber Length:
0.8=0.8m, 1.0=1m, S=Specified
⑦ - Connector Type for
0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, N=None, S=Specified
⑧ - Connector Type for
0=FC/UPC, 1=FC/APC, 2=SC/UPC, 3=SC/APC, N=None, S=Specified

4X4 Fused PM Fiber Splitter Module

4X4 Fused PM Fiber Splitter Module

FAQ

1. What specifications can be customized?

Operating wavelength, package size, pigtail type, fiber length, and connector type can be customized. The ordering information on the page shows that pigtail options include bare fiber, 900μm loose tube, 2.0mm loose tube, and 3.0mm loose tube; fiber length options include 0.8m, 1.0m, or customized; connector options include FC/UPC, FC/APC, SC/UPC, SC/APC, no connector, or customized.


2. How do you ensure product quality and consistency before shipment?

As a professional supplier of polarization-maintaining passive components, we can test insertion loss, additional loss, splitting ratio, extinction ratio, return loss, directivity, port definition, connector endface, and appearance. This page shows that the product is ISO9001 and RoHS certified, with an MOQ of 1 piece and a monthly supply capacity of 100,000 pieces, supporting sample verification and bulk delivery.
