3004 3104 5182 Aluminum Alloy Coil For Beverage Can
3004 3104 5182 Aluminum Alloy Coil For Beverage Can
3004 3104 5182 Aluminum Alloy Coil For Beverage Can
3004 3104 5182 Aluminum Alloy Coil For Beverage Can
3004 3104 5182 Aluminum Alloy Coil For Beverage Can
3004 3104 5182 Aluminum Alloy Coil For Beverage Can
3004 3104 5182 Aluminum Alloy Coil For Beverage Can
3004 3104 5182 Aluminum Alloy Coil For Beverage Can
Specifications
Description


3004 3104 5182 Aluminum Alloy Coil Used For Beverage Can



3004 H19 used for thicker-wall cans (>0.2mm)

3104 H19 dominates 70%+ of global can body production

5182 H48 used for the can tab.


Aluminum Beverage Cans Performance Advantages



① Lightweight Yet Strong

60% lighter than steel cans (standard 330ml can weighs ~13g)

Engineered alloys (e.g., 3004-H19) withstand ≥90 psi pressure (4x CO₂ volume)

② Superior Barrier Properties

100% light/oxygen blocking (prevents UV-induced spoilage, e.g., beer "skunking")

Advanced linings (epoxy/water-based) resist pH 2-12 (juices to alkaline drinks)

③ Thermal Efficiency

Cools 3x faster than glass (15 min chill time) due to 237 W/m·K conductivity

④ Manufacturing Excellence

DWI (Draw & Wall Ironing) process enables thickness gradient (0.28mm→0.10mm)

95% material utilization with speeds up to 3,000 cans/minute


3004 3104 5182 Aluminum Alloy Coil For Beverage Can


Technical Comparison Table



Component Alloy Temper Tensile Strength Key Requirement
Body 3004 H19 ≥290 MPa Pressure resistance + formability
Body 3104 H19 ≥285 MPa High-ratio drawing capability
End 5182 H48 ≥380 MPa Fracture-resistant opening
Tab 5042 H18 ≥320 MPa Precision stamping performance



We have 3104 Aluminum coil sample in our warehouse.



Alloy/Temper Size (mm) Description
6016-F 8X2608xC 26.5ton the Heaviest Hot-Rolled Coil
6061-F 1.5x1000xC the Thinest Hot-Rolled Coil
3104-H19 0.265x1640xC 3104 Can Body Material Coil
2024-T451 2.0x1850xC 2024 Aluminum Alloy for Aviation Application
5454-H32 8x2800xC 2800mm the Widest Hot-Rolled Coil
3004-H24 0.7x2650xC 2650mm super Wide Cold-Rolled Coil





Our Company Product Range



Product Thickness (mm) Width (mm) Length (mm)
Thick plate 6～260 800～4,300 1000～38,000
Thin sheet 0.2～6 1000～2,800 1000～12,000
Hot rolled coil 1.5～12 1050～2,900 ～
Cold rolled coil Min0.1 1000～2,650 ～



Company Advantages



We use the Wolrd Advanced Equipments for your Aluminium Alloy Material


• All the melting and holding furnaces are supplied by GAUTSCHI (Switzerland) Company.
they improve the quality of Aluminum alloy slab which can guarantee Aluminium alloy
products with high-performance.

• 1+1+4 hot rolling mills (1 Reversible Roughing Mill +1 Finishing Mill + 4 Tandem Finishing Mills)
We import these equipments from SMS Group (Germany). All the hot finishing rolling mills
adopt the CVC flatness control technology, which can produce hot rolled coils and plates with
ideal flatness.


Code Name Brand
a aluminum ignot melting furnace GAUTSCHI (Switzerland)
b 2800mm width single stand cold rolling mill SMS Group (Germany)
c 4 continuous hot rolling mills SMS Group (Germany)
d heavy crop and dividing shear SMS Group (Germany)
e coil material annealing furnace SMS Group (Germany)
f all automatic three-dimensional elevated warehouse Dematic (USA)
