6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
Specifications
Brand Name :
JERO
Model Number :
JA72
Certification :
IATF16949 IRIS DNV LR NK
Place of Origin :
CHINA
MOQ :
8 TONS
Price :
3200-3500USD/TON
Payment Terms :
L/C,T/T,Western Union
Supply Ability :
3,500 TONS PER MONTH
Delivery Time :
25-30 WORKING DAYS
Packaging Details :
STANDARD EXPORT PACKAGES
Type :
Aluminum plate
Standard :
ASTM B209
Alloy :
6005
Temper :
O/T5/T6
Thickness :
6.0-260mm
Trade terms :
FOB,CIF,CNF
Description
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
Product Specifications
Attribute Value
Type Aluminum plate
Standard ASTM B209
Alloy 6005
Temper O/T5/T6
Thickness 6.0-260mm
Trade terms FOB, CIF, CNF
Product Overview

6005 is a medium-strength, heat-treatable Al-Mg-Si alloy widely used in structural and architectural applications. It offers an excellent balance of mechanical properties, extrudability, and cost efficiency, making it a popular alternative to 6061 for many industrial uses.

6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
Manufacturing Capabilities
Technological & Production Strengths:
  • R&D Capabilities: Own a national-level corporate technology center and contributes to industry standards.
  • Production Scale: Annual capacity exceeding 1 million tons of aluminium large-scale rolling mills.
  • Production Ability: Can produce high-quality aluminum material for automobile, railway transportation, marine, aerospace fields, with relevant certifications.
Advanced Manufacturing Equipment:
Code Name Brand
A Aluminum ingot melting furnace GAUTSCHI (Switzerland)
B 4 continuous hot rolling mills SMS Group (Germany)
C 2800mm width single stand cold rolling mill SMS Group (Germany)
D All automatic three-dimensional elevated warehouse Dematic (USA)
6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet 6xxx Series 6005 Aluminum Alloy Plate 4x8 Aluminum Sheet
Technical Specifications
Mechanical Properties (T6 temper):
  • Tensile strength: 260-310 MPa
  • Yield strength: ≥240 MPa
  • Elongation: ≥8%
  • Hardness: ~95 HB
Available Tempers:
  • T5: Artificially aged (good strength, lower cost)
  • T6: Solution heat treated + aged (peak strength)
  • O: Annealed (maximum formability)
Key Advantages
  • Excellent strength-to-weight ratio (density: 2.7g/cm³)
  • Superior extrudability (better than 6061)
  • Good corrosion resistance
  • Excellent anodizing characteristics
  • Cost-effective (10-15% cheaper than 6061)
Standard Thickness Ranges
  • Transportation: 1.5-6mm (rail vehicles, racks)
  • Industrial: 3-12mm (robotic frames, conveyors)
  • Construction: 2-5mm (curtain walls, skylights)
  • Electronics: 0.8-3mm (heat sinks, brackets)
Primary Applications
  • Rail transit: High-speed train bodies, door frames
  • Industrial: Automation equipment, robotic arms
  • Architecture: Load-bearing structures, glazing supports
  • Renewable energy: Solar panel frames, battery trays
Application Recommendations
Application Recommended Alloy Reason
Rail transit structures 6005 Best extrudability + cost balance
High-strength components 6061 Highest strength + machinability
Architectural windows/curtain walls 6063 Best surface finish + corrosion resistance
Automotive lightweight parts 6005/6061 Strength-cost optimization
Solar panel frames 6005 Weather resistance + value
