Specifications
Brand Name :
Geosun
Model Number :
gSpin 210
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Payment Terms :
T/T, L/C, Western Union, Credit Card
Delivery Time :
5-8works days
Packaging Details :
Suit Case 220*350*400mm
Material :
Aluminum Alloy Body
Weight :
1.0KG
Storage :
128GB MicroSD Card
Working Temperature :
-20℃-55℃
Processing Software :
PointCloudCreater
Dimensions :
16.5*12.0*32.4cm
Accuracy :
≤1 cm (Relative), ≤5 cm (Absolute)
Data :
Single echo, 200,000Points/Sec
operating time :
2-2.5h
Battery capacity :
11600mAh
Description




Geosun gFireEye Series GS-200G SLAM LiDAR

The GS-200G is a lightweight, high-performance handheld LiDAR system by Geosun Navigation. Featuring the Livox Mid-360 sensor and advanced SLAM algorithms, it captures precise 3D point clouds in GNSS or GNSS-denied environments. Its compact design ensures easy mobility for indoor and outdoor mapping, including urban surveys, infrastructure inspection, and digital twin modeling. Combining LiDAR, GNSS, and INS, the GS-200G delivers reliable, seamless data processing across diverse applications.

Specification of SLAM Scanning System GS-200G


Performance Specs

System Specs

Accuracy
≤1 cm (Relative), ≤5 cm (Absolute)
Voltage Range		 12~20V

Dimensions		 16.5*12.0*32.4cm
Weight		 1.0kg

Operating Temperature		 -20℃-55℃
System Consumption		 ＜25W

Storage
128GB MicroSD Card
Supported Platforms
Handheld/Backpack/Other DIY options available

POS Specs

Model		 gSpin 210
Pitch Accuracy		 0.015°

POS Update Rate		 200HZ
Heading Accuracy		 0.040°

Positioning Accuracy
Horizontal: ±0.02 m/Vertical: ±0.03 m
Roll Accuracy		 0.015°

GNSS Signal Types		 GPS L1/L2；GLO L1/L2；GAL E1/E5b；BDS B1/B3/B2a(Supports BeiDou-only Mode)

Laser Specs

Measuring Range		 40m@10%,70m@80%
Range Accuracy		 ≤2cm@10m ,≤3cm@0.2m

Horizontal FOV		 360°
Vertical FoV		 -7°~52°

Data
Single echo, 200,000Points/Sec
Scanning Mode
Non-repetitive Scanning

Camera Specs

Effective Pixel
2*20MP
FOV
Horizontal/Vertical FoV: 200°

Scanning Mode		 Time-synchronized Scanning

Mapping

Mapping Mode		 SLAM；RTK-SLAM；PPK-SLAM

Indoor/Outdoor Application of SLAM Solution GS-120G
