5mm Accuracy Centimeter RTK GNSS Receiver 20Hz Precise Measurements Accurate Positioning

Specifications

Model Number :

FOIF A60 PRO

Model NO. :

FOIF A60 pro

Type :

Geodesic Receiver

After-Sales Service :

Professional Guidance

Warranty :

1 Year

Accuracy :

5mm

Channels :

800

Working Duration :

Lasts for 10h (Rover)

WiFi :

802.11 B/G/N

Screen :

Smart Touch Screen, Work as a Controller

Update Rate :

10Hz Standard, 20Hz Optional

Transport Package :

Carton

Specification :

35*18*35 cm

Trademark :

FOIF

Origin :

Suzhou, China

HS Code :

8526919090

Production Capacity :

10000

Package Size :

35.00cm * 18.00cm * 35.00cm

Package Gross Weight :

5.000kg

Place of Origin :

China

Brand Name :

CETU

Certification :

MOQ :

Packaging Details :

Carton

Delivery Time :

10-30days

Payment Terms :

T/T advance; Western union; MoneyGram,etc.

Supply Ability :

1000

Price :

$1200-3000

Description

5mm Accuracy Centimeter RTK GNSS FOIF A60 PRO Receiver with 20Hz Update Rate Precise Measurements and Accurate Positioning

1. Linux system, support WebUI page settings

2. 800 channels, support Beidou-3 (ACEBOC), star chain endurance, star station difference

3. Lightweight and miniaturized, all-magnesium alloy body design

4. Four-in-one combination antenna, integrating GNSS, Bluetooth, WIFI, and 4G antennas

5. Colorful LED design, mixed multi-color breathing lights show receiver status

6. Large-capacity lithium battery, comes with 4 battery indicator lights, supports TYPE-C fast charging

7. Built-in Esim, free traffic for three years, network mode operation can be performed without inserting a card

8. New algorithm tilt module, tilt measurement technology without calibration

9. Built-in transceiver integrated radio, full protocol, full frequency, full compatibility

5mm Accuracy Centimeter RTK GNSS Receiver 20Hz Precise Measurements Accurate Positioning

A60 PRO
GNSS	Channels	800
	Satellite Signals	GPS:L1 C/A,L1P,L1C,L2C,L2P,L5
		BDS: B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC
		GLONASS: G1, G2, G3
		Galileo: E1, E5a, E5b, ALTBOC, E6
		QZSS: L1C/A, L1C, L2C, L5, LEX
		SBAS:L1,L5
		L-Band: Optional
	Update Rate	10Hz standard, 20Hz optional
Accuracy	Static	H: ±(2.5+0.5×10-6D)mm ; V: ±(5+0.5×10-6D)mm
Accuracy	RTK	H: ±(8+1×10-6D)mm; V: ±(15+1×10-6D)mm
Power Supply	Battery Capacity	Built-in battery, 4.2V, 6800mAh*2
	Working Duration	lasts for 10h (rover)
	Input Voltage	9~28V DC
	Input Voltage	9~28V DC
System	Operating System	Linux+A7
	Memory	8G, no TF card slot
	Bluetooth	V5.0+EDR, downward compatibility/ BLE
	WIFI	802.11 b/g/n
	Network	All Netcom 4G
	Network	LTE FDD: B1/B3/B5 LTE TDD: B34/B38/B39/B40/B41 WCDMA: B1/B8TD-SCDMA: B34/B39CDMA: BC0 GSM: 900/1800MHz
	Radio	TRM101,410-470MHz
	RTK Fusion	Positioning accuracy of 30° bar tip within 2cm and 60° bar tip within 5cm Note: 1.8 m bar height
Data link	TNC	used to connect inner radio antenna
	Type-C Port	used for charge and date transmission
	5 Pin Port	Used to connect external power and external radio
	Esim	ESim embedded, no need to insert a card can be implemented network mode operation
	SIM Card Slot	Dual-card slot compatible design, embedded ESIM, external SIM card.If the SIM card is inserted, it will use the SIM card by default. If the SIM card is not inserted, it will use ESim by default.At the same time, the user can also choose the use scheme
Physical		148mm*74.5mm, weights about 1.0kg
	Voice	supprt
	Screen	Smart Touch Screen, work as a controller
	Turn on/ off	1) Long press for 3 seconds to turn off the device. (2) Short press once to broadcast the current state, and the four battery level indicator lights will be on for 5s according to the battery level and then off. Shutdown state: (1) Long press for 3 seconds to start the device (2) Shutdown and charging state: four battery level indicators. (3) Short press once (slightly longer than in the power-on state) : the four battery level indicator lights will be on for 5s and then go off.
	Breathing Light Red Red always bright: self - check fault Breathe in Red: Charge less than 25% Red flash: abnormal communication on board card Green 5S one time (500ms green) overlay mixed color: data records, including static, base station, mobile station data records purple Chang Liang: Fixed solution Blink: data link receiving and sending Breathing: single point, successful positioning


	Flash: Not positioned Purple turns blue when bluetooth is connected Yellow boot in.. Yellow flicker self check.. The yellow breath firmware is being upgraded.. Red-green-blue cycle built-in module upgrade...Including network module firmware, board card firmware, sensor firmware, radio firmware 4 electric quantity indicator lights In the charging state, the light flashes according to the remaining charge
Environment	Work Temperature	-30ºC ~ +65ºC
	Storage Temperature	-40ºC ~ +80ºC
	Down Fall	Resistance to 2m fall with pole (hardwood ground), 1.2m free fall.
	Waterproof & dustproof	IP67
	Humidity	anti-condensation 100%

5mm Accuracy Centimeter RTK GNSS Receiver 20Hz Precise Measurements Accurate Positioning
