Single Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With Conveyor
Single Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With Conveyor
Specifications
Certification :
CE
MOQ :
1
Payment Terms :
T/T,L/C
Delivery Time :
30-40working days
Name :
Sandwich Biscuit Machine
Application :
Biscuit
Customized :
Customized
Flavors :
Cream, Jam Filling
Packing Line :
Without Packing Line
Vibrator :
Vibrator Feeding
Capacity :
Max.1400sandwiches/Min.
Feature :
Easy Operate
Biscuit Size :
Diameter 35-65mm
Packaging :
Wooden Case
Origin :
China
HS Code :
8438100010
Brand Name :
LISON
Description
Two Lane Single Flavor Chocolate Cream Filled Biscuit Sandwich Machine With Conveyor
Single Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With Conveyor
Single Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With Conveyor
Single Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With Conveyor
Single Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With Conveyor
Single Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With Conveyor

Product Parameters

Model LSM221X
Product Name Double Lane Single Flavor Biscuit Sandwiching Machine with star wheel sorting conveyor
Total power 4.5kw
Voltage 220V/50Hz
Net weight 500kg
Capacity Max.1400pcs/min.
Biscuit size Round:Φ40-65mm Square:L(40-65)xW(40-65)mm
Products Feature:

(1). PLC for simple operation including machine set-up, hopper controls, speed adjustments.
(2). Cream Shapes: can handle a wide variety of shapes, including round, square, rectangle.
(3). Scrap trays are provided for simple scrap collection and machine cleaning.
(4). Easy to operate: Simple adjustments for machine speeds, cream volume.
(5). Sanitary design with stainless steel for food contact parts, including cream stencil and interchange faster.
(6). Separating cream holding tank and feeding system.
(7). Electric photo sensor No biscuit no cream system.
(8). Temperature metering device installed the cream stencil and convenient change-over stencil design for different cream shapes.
(9). Every cream hopper with independent motor and reducer.
(10). Mobile cream hopper can cleaning while finish working separately.
(11).Stainless steel gear pump, connection tubes between cream hopper and stencil are jacket design.


Our CompanySingle Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With Conveyor
After sales service
The plant & machinery supplied by us will have a guarantee period of 15months from the date of shipment. The guarantee is given against any manufacturing defects or faulty materials. Parts damaged by operator mishandling, improper maintenance,power surges, human sabotage etc. will not be covered by our guarantee.


Packaging and shipping:
The normal package is wrapped with film first, then packing with wooden box. If export to european countries,the wooden box will be fumigated.

If container is too tigher,we will use pe film for packing or pack it according to customers special request.
Single Flavor Sandwich Biscuit Machine Two Lane Filled Cookies Machine With ConveyorShipment: Within 30 working days from the date of receipt the down payment.
Usually by sea, but can also according to customer requirements.
