the assembly will auto feeding the base and top shell , and through detect the exist and the shell direction, then orientation it. After that the strip cutting machine will operate according with the detector and check the length, width and the dirty surface through camera. Then auto fitting it to the shell and pressure it .

The packaging machine will auto feed the bags, desiccant. Then Push the cassette and desiccant to bag, sealing it.

1. cassette base shell feed ->2 direction (upward and downward)check->3 Orientation for upward and downward->4 direction (front and back)check->5 Orientation for front and back->6 strip fitting ->7 strip check->8 cassette top shell fitting->9 top shell check ->10 .top and base shell together and pressure->11 push the finish production to the conveyor
2. push the cassette to packaging machine->13 cassette check->14 bag feeding->15 bag check->16 desiccant feeding ->desiccant check->17 open the bag ->18 push the cassette and desiccant to the bag->19 check it ->20 Sealing the bag->21 defect part ejection ->22 Discharge for the good production
