Specifications
Brand Name :
GBS
Model Number :
GBSFP48150T
Certification :
CE, UL, IEC, TUV,PONY,MA,ISO9001, ISO14001, OHSAS18001
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
Negotiable
Supply Ability :
2000000 PCS PER YEAR
Delivery Time :
15-20 days
Packaging Details :
Dangerous Goods Packaged In Wooden Boxes
Battery Cell Type :
LiFePO4
Battery Cell Capacity :
150AH
Cycle Life :
3000 cycles
Color :
Black or Customized
Warranty :
5 years
Application :
Telecom Base Station, Telecom backup batteries
Size :
3U,4U,5U or customized
Description
Product Description
48V 51.2V 15S 16S 150Ah LFP Battery Moudle 3U 4U 5U for Telecom Base Station Lithium Ion Battery Pack
48V 51.2V 15S 16S 150Ah LFP Battery Moudle 3U 4U 5U for Telecom Base Station Lithium Ion Battery Pack
48V 51.2V 15S 16S 150Ah LFP Battery Moudle 3U 4U 5U for Telecom Base Station Lithium Ion Battery Pack
Basic Performance
  • Output with high efficiency: Standard discharge current is 0.3C-0.8C, instant impulse discharge current is 10C for 10 seconds
  • Good performance under high temperature, it could work under 65°C temperature. The battery structure is safe and reliable
  • Good performance under low temperature: discharge capacity decreases to over 78% under 0°C and discharge capacity decreases to over 70% under -20°C
  • Excellent safety performance: Features a one-way safety valve that releases gas and heat when internal pressure becomes too high, preventing burning and explosion
  • Long cycle life: Discharge capacity remains over 80% after 2000 cycles at 80% depth of discharge (DOD)
  • Fast charging capability: Charges to 80% within 20 minutes and fully charges in 2-3 hours
  • Cost-effective solution with low maintenance requirements
  • Environmentally friendly: No pollution during manufacture or usage
Installation & Usage Guidelines
  • Verify all components are present upon unpacking and carefully review the operation manual
  • Avoid short circuits, overcharging, and over-discharging the battery
  • For first use, fully charge the battery before initial discharge
  • Do not remove the factory-installed plates and strips from the battery pack
  • Standard voltage range: 12.8V-13.2V (verify before installation)
  • Always use the Battery Management System (BMS) to protect individual cells from overcharge/discharge
  • Battery connectors use rivets or screws for secure attachment
  • Use copper components for inter-battery connections, secured with hydraulic pressure pliers (screw-fixed connections available upon request)
  • Only use chargers approved by our company specifically designed for our lithium batteries
Failure to follow these guidelines may void warranty coverage and reduce battery lifespan
Safety Assurance Requirements
For optimal safety and performance, please consult with our technical team regarding:
  • Equipment design considerations
  • System integration requirements
  • Protection circuit specifications for Lithium-ion cells
  • High-rate current applications
  • Rapid charge implementations
  • Special application requirements
