Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Specifications
Brand Name :
SWET
Model Number :
LDR0.3-0.8-3004
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
1500 Set/Sets Per Year
Delivery Time :
25-30 work days
Packaging Details :
The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements
Steam capacity :
300 kg/h
Input power :
216kW
Rated current :
324 A
Main voltage :
380 V
Overall dimension (L×W×H) :
1320×1040×1920 mm
Model :
LDR0.3-0.8-3004
Description

Vertical 300 Kg Easy To Use Electric Steam Boiler With No Noise


Product description

1. Small boiler body, mechanical and electrical integration, easy to install and match

2. Large boiler furnace and electronic control split design, to eliminate the electrical control by the furnace temperature, to ensure the stable operation of electronic control devices.

3. Compact structure, scientific and rational design and advanced manufacturing technology, so that the boiler space is small, easy to transport and save the use of venues.

Product advantages

1. Small scientific design

2. unique internal structure design

3. One-stop electronic control system

4. multiple chain security features

Application


Fully automatic electric steam boiler / electric heating steam boiler widely used in hospitals, schools, textile mills, garment factories, garment supermarkets, garment factories, dry cleaners,


Product parameters

Specfications for automatic electric steam boiler
Model

LDR0.15-0.8

LDR0.2-
0.8

LDR0.25-0.8

LDR0.3-
0.8

LDR0.4-
0.8

LDR0.5-
0.8
Item Unit
Steam capacity kg/h 150 200 250 300 400 500
Rated pressure MPa 0.8 0.8 0.8 0.8 0.8 0.8
Saturated steam temperature C

175

175

 175 175 175 175
Input power kW

108

144

 180 216 288 360
Rated current A

167

216

 270 324 432 540
Main voltage V

380

380

 380 380 380 380
Steam outlet valve dia. DN

25

25

 32 32 32 40
Safety valve dia. DN

25

25

 25 25 32 40
Water inlet dia. DN

20

20

 25 25 25 25
Blow-down valve dia. DN

25

25

 32 32 32 32
Overall dimension (L×W×H) mm

920×760
×1390

1130×750
×1780

950×900
×1830

1320×1040
×1920

1380×1040
×2070

1020×890
×2350
Net weight kg 2485 450 650 760 890 1020

Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
Vertical 300 Kg Electric Steam Boiler 216kW Input Power ISO9001 Standard
