220V Commercial Electric Steam Boiler 36 KW Input Power 55A Output Current
220V Commercial Electric Steam Boiler 36 KW Input Power 55A Output Current
220V Commercial Electric Steam Boiler 36 KW Input Power 55A Output Current
220V Commercial Electric Steam Boiler 36 KW Input Power 55A Output Current
220V Commercial Electric Steam Boiler 36 KW Input Power 55A Output Current
220V Commercial Electric Steam Boiler 36 KW Input Power 55A Output Current
220V Commercial Electric Steam Boiler 36 KW Input Power 55A Output Current
220V Commercial Electric Steam Boiler 36 KW Input Power 55A Output Current
Specifications
Brand Name :
SWET
Model Number :
LDR0.05 -0.7-3010
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram，Cash or on the basis of mutual agreement
Supply Ability :
1500 Set/Sets Per Year
Delivery Time :
25-30 work days
Packaging Details :
The boiler in nude package, but covered with water-proof covering, accessories in plywood case or tin case, this can be changed as your requirements
Rated evaporation :
50 kg/h
Fixed work stress :
0.7mpa
input power :
36 KW
Output current :
55 A
Rated voltage :
220/380 V
Model :
LDR0.05 -0.7-3010
Dimensions Length × width × height :
900×650 ×1150 mm
weight :
132 Kg
Description

220V New Type Vertical Quick Electric Steam Boiler For Commercial


Product description

1. The water supply system is the throat of automatic steam generator, an endless supply of dry steam to users.

2. When the water source into the tank, turn on the power switch, driven by the automatic control signal, high temperature solenoid valve open, pump work, through the one-way valve injection furnace.

3. When the solenoid valve, one-way valve is blocked or damaged, when the water supply reaches a certain pressure will be over pressure valve overflow back to the tank, thus protecting the pump.

Product advantages

1. Intelligence,high configuration,security,convenience,reasonableness

2. Boiler can be continuous operation can also be timed to work, without special duty, usually just press the "start" button to boot, press the "stop" button to stop, very simple.

Application

1. Washing ironing industry

2. Food machinery industry

3. Biochemical industry

4. Other industries: (oil, automobile) steam cleaning industry

Product parameters

model

LDR0.004

-0.4

LDR0.013

-0.7

LDR0.024

-0.7

LDR0.035

-0.7

LDR0.05

-0.7

LDR0.08

-0.7

LDR0.1

-0.7

 LDR0.15-0.7
project unit
Rated evaporation Kg/h 4 13 24 35 50 80 100 150
Fixed work stress Mpa 0.4 0.7 0.7 0.7 0.7 0.7 0.7 0.7

Saturated

steam temperature

 ℃

151

 171 171 171 171 171 171 171
input power KW 3 9 18 24 36 54 72 108
Output current A 6 14 27 41 55 79 113 164
Rated voltage V 220/380 380 380 220/380 220/380 380 380 380
Intake pipe diameter DN 15 15 15 15 15 15 15 15
Main steam valve caliber DN 15 15 15 15 15 15 20 25
Safety valve caliber DN 15 15 15 15 15 15 40 25

Dimensions

 mm

680×520

×850

750×550

×920

850×600

×1000

850×600

×1000

900×650

×1150

900×650

×1200

880×870

×1300

1010×740

×1210
weight Kg 50 79 92 118 132 150 280 160
