Specifications
Brand Name :
SWET
Model Number :
LSS0.3-0.7-S-3014
Certification :
ISO9001
Place of Origin :
Henan China
MOQ :
1 Set/Sets
Price :
Negotiation
Supply Ability :
1000 Set/Sets Per Year
Delivery Time :
10-15 work days
Packaging Details :
The biomass steam generator is covered with a waterproof film and the transport package is a wooden box.
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Rated evaporation :
300kg/h
Weight :
1150kg
Style :
Vertical
Design fuel :
Biomass
Usage :
Industrial,Garment manufacturer
Type :
Natural Circulation,Once Through /Auxiliary Cycle
Fuel :
Oil,Gas,Oil/Gas-fired
Condition :
New
Output :
Steam
Pressure :
Low Pressure,High Pressure
Structure :
Fire Tube,Water Tube
Application :
Industrial Production,Machinery Industry,Hospital,chemical industry,Food Factory
Steam temperature :
170-204℃,194 ℃,≤194℃
Description

LSS 0.7Mpa 300Kg/h Biomass Pellet Steam Boiler For The Machinery Industry

Product description

1. Environmental protection and durability: biomass steam boiler with a new multi-tube cyclone dust collector and energy-saving integrated structure, greatly reducing the flue gas temperature, improve thermal efficiency

2. The steam boiler fuel is energy-saving and environmentally friendly biomass. It is renewable, wide range of sources, affordable, and its running cost is one sixth of electric boiler, and a third of oil-fired boiler. There is no smoke and dust put off when burning.

3. The steam generator built-in steam separator solves the problem of steam with water to ensure the quality of the steam.

4. The steam generator full automatic control. Just connect the water and electricity; press the key, then the boiler will automatically enter the automatic running, safer and more convenient .

Product advantages

1. The biomass steam boiler is compact in structure, small in size, elegant in appearance, easy in installation and low in failure rate.

2. Simple operation: automatic feeding, ultra-low feeding, hopper to increase design, simple operation, small workload, single duty can be

3. Modular machine factory has been configured to make up the pump and solenoid valve, just connected to the power supply, the water inlet pipe can be, saving installation costs and a lot of installation materials;

4. Energy saving fuel, is a renewable resource, operating costs is one sixth of electric boilers, oil boiler is one-third;

5. The overall modular factory, small size, less than half a ton of steam boiler buckle with this steam generator module combination of alternative solutions

Generator product model LHS0.1-0.7-S LHS0.15-0.7-S LSS0.2-0.7-S LSS0.3-0.7-S LSS0.4-0.7-S YDZ0.5-0.7-S
preset pressure(Mpa) 0.7 0.7 0.7 0.7 0.7 0.7
Rated steam temperature(℃) 170 170 170 170 170 170
Rated evaporation(Kg/h) 100 150 200 300 400 500
Maximum fuel consumption(Kg/h) 17 25 34 47 65 80
Thermal efficiency 85% 85% 85% 85% 85% 85%
weight(Kg) 600 700 1020 1150 1600 2700
Dimensions(Length × width × height)mm

1600*900

*1900

1600*900

*1900

2150*950

*2400

2000*1400

*2700

2700*1100

*2450

2200*1500

*2500
