Specifications
Brand Name :
SWET
Model Number :
LSS-6003
Certification :
ISO9001
Place of Origin :
HENAN,CHINA
MOQ :
1 SET
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
3000 SETS PER YEAR
Delivery Time :
10 WORKING DAY
Packaging Details :
The 500kg steam generator bady with plywood packaging.
Product name :
500kg gas steam boiler
Item :
LSS-6003 gas steam boiler
Design fuel :
gas/oil
Color :
Customer's Requirement
Warranty :
12 Months
Thermal efficiency :
over 90%
The biggest fuel consumption(Nm3/h) :
37.9
Rated evaporation (kg/h) :
500
Rated steam temperature(℃) :
170
Rated steam pressure(Mpa) :
0.7
Size :
3200x1500x2100mm
Fuel :
Gas-fired,Oil-fired,gas
Usage :
Industrial
Type :
Natural Circulation,Once Through,Gas Fired Steam Generator
Description

500KG full automatic control gas diesel steam boiler

1. The steam generator fuels are renewable biomass; the running cost is one fifth of electric boiler, one third of oil boiler.

2. The steam generator full automatic control. Just connect the water and electricity; press the key, then the boiler will automatically enter the automatic running, safer and more convenient.

3. The steam generator Easy installation; no need to ask for a professional installation personnel to install, meanwhile saving a lot of installation materials.

4. Environmental protection and durability: biomass steam generator with a new multi-tube cyclone dust collector and energy-saving integrated structure, greatly reducing the flue gas temperature, improve thermal efficiency, environmental protection requirements to meet the new national standards.

Gas steam boiler technical parameters

Gas steam boiler technical parameter
Rated evaporati on Rated pressure Rated steam temperat ure Feed water temperat ure Design thermal efficienc y Water capacit y Steam outlet water intake Drain valve Gas supply pressur e Gas pipe diamet er Dimensions Shippin g weight Full load biomass consuption
L W H
Kg/h Mpa ℃ ℃ % L DN DN DN Kpa DN mm mm mm T Nm³/h
80 0.7 170℃ 20℃ 90% 27 15 15 20 2-3.5 20 1050 1000 1500 0.6 6.5(NG)
100 0.7 170℃ 20℃ 90% 27 15 15 20 2-3.5 20 1150 1100 1600 0.5 8.4(NG)
150 0.7 170℃ 20℃ 90% 27.6 15 15 20 2-3.5 20 1250 1200 1700 0.7 11.7(NG)
200 0.7 170℃ 20℃ 90% 27.6 20 15 25 2-3.5 20 1600 1500 2300 1.2 15.7(NG)
300 0.7 170℃ 20℃ 92% 28 32 15 25 3.5-5 20 1700 1600 2300 1.3 22.3(NG)
400 0.7 170℃ 20℃ 92% 28.6 32 15 25 3.5-5 32 2350 1750 2200 2.8 30.5(NG)
500 0.7 170℃ 20℃ 92% 29 40 15 25 3.5-5 32 3200 1500 2100 3 37.9(NG)
600 0.7 170℃ 20℃ 92% 29 40 15 25 3.5-5 32 3200 1500 2500 4.2 46.9(NG)

Diesel / Gas Steam Boiler Integrated Structure With Customized ColorDiesel / Gas Steam Boiler Integrated Structure With Customized Color

Diesel / Gas Steam Boiler Integrated Structure With Customized Color
