Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
Specifications
Brand Name :
Gnee
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Description

Steel bar grating, known for its high strength and robust structure, is manufactured from carbon steel, aluminum, or stainless steel. Depending on the production method, steel grating can be categorized into four types: welded bar grating, press-locked grating, swage-locked grating, and riveted grating. Based on surface design, it is available in both smooth and serrated options. With a wide range of styles and sizes, steel grating serves versatile applications in everyday life, including stair treads, walkways, platforms, flooring, trench covers, wheeled equipment, security screens, and heavy-duty constructions.


Pitch of Bearing bar Cross-bar Pitch Specification of bearing bar(widthxthickness)


20×3 25×3 32×3 40×3 20×5 25×5
30 100 G203/30/100 G253/30/100 G323/30/100 G403/30/100 G205/30/100 G255/30/100

50 G203/30/50 G253/30/50 G323/30/50 G403/30/50 G205/30/50 G255/30/50
40 100 G203/40/100 G253/40/100 G323/40/100 G403/40/100 G205/40/100 G255/40/100

50 G203/40/50 G253/40/50 G323/40/50 G403/40/50 G205/40/50 G255/40/50
60 50
G253/60/50 G253/60/50 G403/60/50 G205/60/50 G255/60/50
Pitch of Bearing bar Cross-bar Pitch Specification of bearing bar(widthxthickness)


32×5 40×5 45×5 50×5 55×5 60×5
30 100 G325/30/100 G405/30/100 G455/30/100 G505/30/100 G555/30/100 G605/30/100

50 G325/30/50 G405/30/50 G455/30/50 G505/30/50 G555/30/50 G605/30/50
40 100 G325/40/100 G405/40/100 G455/40/100 G505/40/100 G555/40/100 G605/40/100

50 G325/40/50 G405/40/50 G455/40/50 G505/40/50 G555/40/50 G605/40/50
60 50 G325/60/50 G405/60/50 G455/60/50 G505/60/50 G555/60/50 G605/60/50


Surface Treatment
We provide four finishes for anti-corrosion treatment of carbon steel bar grating:
Black / Bare Steel: No finish, life is very short, but the price is the cheapest.
Painted Coat: The anti-rust effect is general and can be any color.
Electro-galvanized: A small amount of zinc coating, easy to cause slight corrosion in humid environment.
Hot-dip galvanized: The most commonly used method to provide the best anti-rust effect, strictly in accordance with ASTM A123 or GB/T 13912-2002.


Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels

Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels

Hot-DIP Galvanized Heavy Duty Stainless Welded Steel Grating Metal Grating Panels
