Standard Welded Steel Grating Galvanized Steel Grating Walkway Platform
Standard Welded Steel Grating Galvanized Steel Grating Walkway Platform
Standard Welded Steel Grating Galvanized Steel Grating Walkway Platform
Standard Welded Steel Grating Galvanized Steel Grating Walkway Platform
Standard Welded Steel Grating Galvanized Steel Grating Walkway Platform
Standard Welded Steel Grating Galvanized Steel Grating Walkway Platform
Specifications
Brand Name :
GNEE
Certification :
SGS
Place of Origin :
China
Price :
Negotiable
Payment Terms :
Negotiable
Supply Ability :
100 ton/week
Packaging Details :
Sea-worthy packing, ie wooden or steel tray with steel strip,etc
Description

Galvanized Welded Metal Steel Grating, also known as bar grating or metal grating, is an open grid assembly of metal bars, in which the bearing bars, running in one direction, are spaced by rigid attachment to cross bars running perpendicular to them or by bent connecting bars extending between them, which is designed to hold heavy loads with minimal weight. It is widely used as floors, mezzanines, stair treads, fencing, trench covers and maintenance platforms in factories, workshops, motor rooms, trolley channels, heavy loading areas, boiler equipment and heavy equipment areas, etc.

Standard Welded Steel Grating Galvanized Steel Grating Walkway Platform

Item
Description
Bearing Bar
25x3, 25x4, 25x4.5, 25x5, 30x3, 30x4, 30x4.5, 30x5, 32x5, 40x5, 50x5, 65x5, 75x6, 75x10---100x10mm etc
I bar: 25x5x3, 30x5x3, 32x5x3, 40x5x3 etc
US standard: 1''x3/16'', 1 1/4''x3/16'', 1 1/2''x3/16'', 1''x1/4'', 1 1/4''x1/4'', 1 1/2''x1/4'', 1''x1/8'', 1 1/4''x1/8'', 1
1/2''x1/8'' etc
Bearing Bar Pitch
12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 32.5, 34.3, 35, 38.1, 40, 41.25, 60, 80mm etc
US standard: 19-w-4, 15-w-4, 11-w-4, 19-w-2, 15-w-2 etc.
Twisted Cross Bar Pitch
38.1, 50, 60, 76, 80, 100, 101.6, 120mm, 2'' & 4'' etc
Material Grade
ASTM A36, A1011, A569, Q235, S275JR, SS304, SS400,
Mild steel & Low carbon steel, etc
Surface Treatment
Black, self colour, hot dip galvanized, painted, spray coating
Grating Style
Plain / Smooth, Serrated /teeth, I bar, serrated I bar

Standard Welded Steel Grating Galvanized Steel Grating Walkway Platform
