Mild Steel Heavy Duty Steel Grating 75mm x 6mm Metal Drain Grates Steel Bar Grating
Mild Steel Heavy Duty Steel Grating 75mm x 6mm Metal Drain Grates Steel Bar Grating
Mild Steel Heavy Duty Steel Grating 75mm x 6mm Metal Drain Grates Steel Bar Grating
Mild Steel Heavy Duty Steel Grating 75mm x 6mm Metal Drain Grates Steel Bar Grating
Specifications
Model Number :
HDSG
Certification :
ISO9001
MOQ :
2PCS
Supply Ability :
300000 Square Meter/Square Meters per Month
Delivery Time :
Shipped in 20 days after payment
Packaging Details :
Fix with metal belt Packing with pallet ,outside wrap with waterproof plastic film Finial in container
Name :
Mild Steel Heavy Duty Steel Grating 75mm x 6mm Hot Dipped Galvanized
Surface treatment :
Hot dipped galvanized,Untreated,painted
Cross bar size :
8mmx8mm
Bearing bar pitch :
30,40.customized requirement
Cross bar pitch :
100mm
Application :
Airfields,Highways,Industrial Floors,Ramps,Docks,Reinforced Concrete Areas
Galvanization Standard CN :
GB/T13912, US: ASTM (A123), UK: BS729
Standard CN :
YB/T4001-1998, US: ANSI/NAAMM, UK: BS 4592-1987, AU 16571988, JJ
Description

Mild Steel Heavy Duty Steel Grating 75mm x 6mm Hot Dipped Galvanized

Steel grating is made by the world first-class equipment, which can arrange the bearing bar and cross bar in longitude and latitude order to certain distance. Cross bar is pressed into the bearing bar by high tension resistance welding ring which is controlled by computer. So we can produce high quality gratings with firm welding, smooth surface and high strength.

1. Steel Grating Material:Q235 Steel or stainless steel grating.
2. Steel Grating Surface Treatment: Untreated, Painting or Hot Dipped Galvanizing

Heavy Duty Grating Specification

Load Bearing Flat Bar size Thickness≥6mm, depth ≥50mm
50X6,50X6,60X6,75X8,100X8,100X10mm……
Pitch of Load bearding flat bars (mm) 20, 30, 30.6,32.5, 34,34.8,35.3, 40, 60, 80……
Pitch of cross bars (mm) 38.1, 50, 50.8, 70, 75, 80, 100, 101.6, 102……

3. Size:The sizes 6meter x1 meter ,5.8meter x 1meter are the common size to Aisan and Middle East markers.
The plain galvanized steel grating commonly used on bridge,refinery ,power plant,Sewage treatment plant and so on.
4. Standards:
A) China: YB/T4001.1-2007
B) U.S.A.: ANSI/NAAMM (MBG531-88)
C) U.K.: BS4592-1987
D) Australia: AS1657-1985

E) Japan: JJS
5. Hot Dipped Galvanizing Standards:
A) China: YB/T4001-1998
B) USA: ANSI/NAAMM (MBG531-88)
C) UK: BS4592-1987
D) Australia: AS1657-1985
6. Application
Steel grating can be widely used in petrochemical,water plants,sewage treatment
plants,municipalengineering,environmental engineering and other fields of platforms, walkways, trestlebridge, ditch cover, covers, ladders, fences and railings etc.

Bar Size Inches: Weight Per Sq.Ft: Sect.Prop.Ft. Of Width:
1-1/4x1/4 12.08 Sx=0.642/1x=0.420
1-1/4x3/8 17.55 Sx=1.009/1x=0.63
1-1/2x1/4 14.35 Sx=0.969/1x=0.726
1-1/2x5/16 17.55 Sx=1.211/1x=0.908
1-1/2x3/8 20.86 Sx=1.452/1x=1.089
1-3/4x1/4 16.52 Sx=1.318/1x=1.153
1-3/4x3/8 24.16 Sx=1.977/1x=1.730
2x1/4 17.56 Sx=1.722/1x=1.722
2x5/16 23.13 Sx=2.152/1x=2.152
2x3/8 27.47 Sx=2.583/1x=2.583
2-1/4x1/4 20.86 Sx=2..179/1x=2.451
2-1/4x3/8 30.78 Sx=3.268/1x=3.677
2-1/2x1/4 23.13 Sx=2.690 / 1x=3.362
2-1/2x5/16 28.61 Sx=3.362 / 1x=4.203
2-1/2x3/8 34.08 Sx=4.035 / 1x=5.044
3x1/4 28.89 Sx=3.874 / 1x=5.810
3x5/16 35.50 Sx=4.843 / 1x=7.263
3x3/8 42.11 Sx=5.811 / 1x=8.716
3-1/2x1/4 33.33 Sx=5.272 / 1x=9.226
3-1/2x3/8 48.62 Sx=7.909 / 1x=13.840
4x1/4 37.67 Sx=6.886 / 1x=13.772
4x5/16 46.45 Sx=8.608 / 1x=17.215
4x3/8 55.23 Sx=10.330 / 1x=20.660
4-1/2x1/4 42.11 Sx=8.716 / 1x=19.610
4-1/2x3/8 61.84 Sx=13.074 / 1x=29.416
5x1/4 46.45 Sx=10.761 / 1x=26.901
5x5/16 57.40 Sx=13.451 / 1x=33.626
5x3/8 68.46 Sx=16.141 / 1x=40.352
5-1/2x1/4 50.89 Sx=13.020 / 1x=35.804
5-1/2x3/8 74.69 Sx=19.530 / 1x=53.707
6x1/4 55.23 Sx=15.495 / 1x=46.485
6x5/16 68.46 Sx=19.369 / 1x=58.106
6x3/8 81.57 Sx=23.343 / 1x=69.127
Note: Sx = (Sec. Mod. Ft Width) 1x = (Mom. of Inertia Ft. Width)


Mild Steel Heavy Duty Steel Grating 75mm x 6mm Metal Drain Grates Steel Bar Grating

Product tags

galvanized steel bar grating specification

,

galvanized steel bar grating

,

open steel grating
