Stainless Steel 2PC Ball Valve, Flange End, Direct Mounting Pad ,150LB / 300LB, PN16-40
Stainless Steel 2PC Ball Valve, Flange End, Direct Mounting Pad ,150LB / 300LB, PN16-40
Stainless Steel 2PC Ball Valve, Flange End, Direct Mounting Pad ,150LB / 300LB, PN16-40
Stainless Steel 2PC Ball Valve, Flange End, Direct Mounting Pad ,150LB / 300LB, PN16-40
Specifications
Packaging Details :
According to customer's requirements
Delivery Time :
Delivery Time within 20days
Place of Origin :
China
Brand Name :
Yh
Price :
Depends on order quantity
Payment Terms :
LC and TT
Description

Stainless Steel 2PC Ball Valve, Flange End, Direct Mounting Pad ,150LB / 300LB, PN16-40

Specifications

Stainless Steel 2PC Ball Valve,Flange End, Direct Mounting Pad ,150LB/300LB,PN16-40
1)Material:CF8M,CF8,WCB
2)Sizes:1/4"-8"

Certificates:CE,ISO9001

Sample is available upon your request

Agent wanted

1)Descriptions:

·Design Stardard :ASME/ANSI B16.34,EN12516-1

·Blow-out Proof Stem

·Anti-Static Device for Ball-Stem-Body

·Pressure Blance Hole in Ball Slot

·2 Belleville Washer to Self-adjust Packing

·ISO 5211 Direct Mounting Pad for Easy Automation

·Locking Device Spring Handle Available

·Fire Safe Design Availble: API 607

·Body Material: Stainless steel (ASTM A351-CF8M/CF8)

Carbon steel (ASTM A216-WCB)

·Connection types: Flange End

·Flange End Standard: ASME B16.5 CLASS 150LB/300LB

DIN PN10-PN40,JIS B2220 10K/20K

·Testing&Inpection: API 598,EN 12266
·Size range: NPS 1/2" to 6",DN 15 to DN150

·Working pressure: 1000W.O.G

·Working Temperaure: from -20°C to 190°C

·Working Medium: Water, Oil, Gas, Acid, etc

2)Packing:Paper box ,Plywood cases

3)Payment term: T/T,L/C at sight,

4)Brand:WONSTON(OEM)

5)Delivery time: 45 days
