PVC Coated Gabion Basket Gabion Box For Stone Retaining Wall
PVC Coated Gabion Basket Gabion Box For Stone Retaining Wall
Specifications
Brand Name :
KN
Model Number :
gabion cages
Certification :
CE ISO SGS COC PVOC
Place of Origin :
CN
MOQ :
100 pc
Price :
USD 15-17
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
500 pc per day
Delivery Time :
15 work days
Packaging Details :
pallet
Product Name :
PVC Coated Gabion Basket Gabion Box For Stone Retaining Wall
Key Words :
gabion basket
Lacing_Wire :
2.2mm
Gabion Basket Size :
1*1*1m, 2*1*1m, 3*1*1m, 4*1*1m
Mesh_Type :
hexagonal
Application :
erosion control, retaining walls, landscaping, etc.
Sample :
Available and free
Zinc Coating :
≥ 240g/m²
Description
PVC Coated Gabion Basket Gabion Box For Stone Retaining Wall
Woven gabion mesh is a type of wire mesh used to construct gabion baskets or cages, which are commonly applied in civil engineering, erosion control, and landscaping projects. The mesh is made by weaving steel wires — typically galvanized or PVC-coated for corrosion resistance — in a double-twisted or hexagonal pattern. This weaving method gives the mesh excellent flexibility and strength, allowing it to withstand earth pressure, water flow, and settlement without breaking. Woven gabion mesh is usually supplied in rolls or prefabricated panels, and the gabion baskets are filled with stones or rocks to form retaining walls, riverbank protections, weirs, or decorative landscape features. Its open structure permits drainage and vegetation growth, making it both functional and environmentally friendly.
Key Product Features
  • Product Name: Gabion Box
  • Standard Sizes: 1m × 1m × 1m, 2m × 1m × 1m, 3m × 1m × 1m
  • Available Colors: Silver, Green, Black
  • Mesh Sizes: 80mm × 100mm, 60mm × 80mm, 100mm × 120mm
  • Primary Applications: Soil retaining, flood control
Technical Advantages
  • Extended Lifespan: 50-100 years corrosion resistance
  • High Load Capacity: Up to 50kN/m² vertical pressure
  • Eco-Friendly: 100% recyclable materials with zero chemical runoff
  • Modular Assembly: Interlocking panels enable 70% faster installation
Product Name Gabion Box
Packing Pallet, Bundle
Material Galvanized Steel Wire, PVC Wire, Galfan Wire
Size 1m × 1m × 1m, 2m × 1m × 1m, 3m × 1m × 1m
Price Negotiable
Surface Treatment Heavy Zinc Coated
Color Silver, Green, Black
Application Soil Retaining, Flood Control
Certification ISO9001
Wire Diameter 3.0mm, 2.7mm
Lifespan 20-30 Years
Key Features Gabion Retaining Wall, Gabion Mattress, Gabion Basket
Project Specifications
Minimum order quantity of 100 pieces with negotiable pricing. Standard packaging of 100 pieces per bundle for convenient transportation and storage. Quick delivery within 7 days ensures timely project completion.
Customization Services
  • Sizes: 2×1×1m (standard) up to 6×2×1m (heavy-duty)
  • Wire Diameters: 2.2mm - 4.0mm (3.0mm recommended for high-load zones)
  • Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
