Radiation Shielding XRF Fusion Machine Sample Preparation XRF Analysis Machine
Radiation Shielding XRF Fusion Machine Sample Preparation XRF Analysis Machine
Specifications
Analysistime :
30 Seconds To 3 Minutes
Delivery Time :
30days
Productname :
XRF Fusion Machine
Place of Origin :
Chengdu china
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Safetyfeatures :
Radiation Shielding, Interlock Protection
Dimensions :
600mm X 500mm X 400mm
Measurementrange :
Ppm To 100%
Application :
Material Composition Analysis
Brand Name :
Guiheng
Model Number :
XRF High-frequency Fusion Sample Equipment 4ZC
Place Of Origin :
XRF High-frequency Fusion Sample Equipment 4ZC
MOQ :
1set
Measurementmethod :
XRF (X-ray Fluorescence)
Softwarefeatures :
Quantitative Analysis, Qualitative Analysis, Data Export
Certification :
ISO
Description
Table 1: Main parameters of equipment

Unit type

GH-4ZC

Maximum output

12KW (fused and molded power supply output power)

Range of oscillation frequencies

50KHz-80KHz

Range of current regulation

35A-130A

Time adjustment range

0s-999s

Forming mode

Auto

Sample production per batch

4

Cooling water pressure

0.1-0.3MPa

Program storage

More than 10 groups

Fusion temperature

0-1300℃ (adjustable)

Temperature control accuracy

±1℃

Stirring method

Centrifugal rotation + positive reversal (exclusive patent)

Rotational speed range ★

0-180 rpm / min (adjustable)

Speed change period ★

N. times / min (adjustable)

Infrared temperature measurement range

400℃-1200℃

Main dimensions (length, width and height)

1160*660*1100mm

Host net weight

390kg

Tank shape size

990x690x1530mm

Water tank net weight

130kg

"★" Mark is the unique technical parameter of Guiheng Company
