Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
Specifications
Brand Name :
Furious Motor
Model Number :
70141
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
$313
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
3000 pcs per month
Delivery Time :
5-8 working days
Packaging Details :
Carton witn protection (EPE)
Model :
70-141
Dimension :
70mm * 141mm
KV :
120
Max. Thrust :
52KG
Max. Torque :
9 N.m
Max. RPM :
6600
Suggested ESC :
14S 160A
Suggested Prop :
PD-1
Max. Current :
78A
Max. Voltage :
57V
Max. Power :
4KW
Li - Po :
12S - 14S
Hall Sensor :
Optional
Weight :
1.9KG
Application :
Efoil, electric boat
Description

Intoroduction

The 70141 Propulsion System is a high-performance solution built for aquatic applications, delivering up to 50kg of thrust with its powerful BLDC motor. Designed for precision and efficiency, it pairs perfectly with the DP-1 propeller, 14S 160A ESC, and DC-2 controller, ensuring smooth and responsive control.

Ideal for underwater thrusters, e-foils, electric surfboards, and underwater scooters, this system provides the power and reliability needed for an exceptional ride on or beneath the water.

Tech Specs

Model 70-141
Type Brushless DC motor
KV 120
Suggested ESC 14 S 160 A
Suggested Propeller PD-1
Max. Thrust 52 kg
Max. Torque 9 N·m
Max. RPM 6600
Li-Po 8 S ~ 14 S
Max. Voltage 57 V
Max. Current 78 A
Max. Power 4 kW
Motor Dimension 70 mm * 141 mm
Weight 1.9 kg
Application Electric surfboard, efoil, underwater thruster, electric boat

Details

Efoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric SurfboardEfoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric SurfboardEfoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric SurfboardEfoil DC Brushless Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard

Efoil Brushless DC Motor IP68 Waterproof Motor With 52kg Thrust For Electric Surfboard
