58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller
58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller
58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller
58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller
58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller
58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller
58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller
58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller
Specifications
Brand Name :
Furious Motor
Model Number :
75141
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
$707
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
3000 pcs per month
Delivery Time :
5-8 working days
Packaging Details :
Carton witn protection (EPE)
Model :
75141
Dimension :
75mm * 141mm
KV :
100
Max. Thrust :
58KG
Max. Torque :
11.9N.m
Max. RPM :
5500
Suggested ESC :
14S 160A
Suggested Prop :
PD-1
Max. Current :
120A
Max. Voltage :
55V
Max. Power :
6.8KW
Li - Po :
12S - 14S
Hall Sensor :
Optional
Weight :
2KG
Application :
Efoil, electric boat.
Description

Intoroduction

The 75141 Propulsion System is built for high-performance aquatic applications, delivering up to 56kg of thrust with its powerful BLDC motor. Engineered for precision and reliability, it pairs seamlessly with the DP-3 propeller, 14S 160A ESC, and DC-2 controller to ensure smooth and efficient operation. Designed for underwater thrusters, e-foils, electric surfboards, and underwater scooters, this system provides the power and control needed for an exhilarating ride on or beneath the water.

Tech Specs

Motor

Model 75141
Type Brushless DC motor
KV 100
Suggested ESC 14 S 160 A
Suggested Propeller PD-2
Max. Thrust 58 kg
Max. Torque 11.9 N·m
Max. RPM 5500
Li-Po 8 S ~ 14 S
Max. Voltage 57 V
Max. Current 120 A
Max. Power 6.8 kW
Motor Dimension 75 mm * 141 mm
Weight 2 kg
Application Electric surfboard, efoil, underwater thruster, electric boat

ESC

Model 14 S 160 A
Suggested Battery 6 S ~ 14 S (Li-Po)
BEC 5 V 1 A
Signal Frequency 50 Hz ~ 400 Hz
Max. Input Voltage 58 V
Max. Current 200 A
Weight 550 g
Dimension 92 mm * 46 mm * 23 mm

Details

58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller

58KG Thrust Electric Surfboard Brushless DC Motor With Propeller And Remote Controller Included
