LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
LPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
Specifications
Brand Name :
IMPCO
Model Number :
Model T52
Certification :
UL
Place of Origin :
USA
MOQ :
24
Payment Terms :
T/T
Supply Ability :
1200pcs per 8weeks
Delivery Time :
8 weeks
Packaging Details :
carton
Material :
Aluminum
Fuel Type :
LPG Vapor or Natural Gas
Operating Temperature Range :
-40°F to +250°F (-40°C to +121°C)
HP/KW Rating :
T52B 40 hp (29.8 kW) LPG Vapor/25 hp (18.6 kW) Natural Gas; T52N 15 hp (11.2 kW) LPG Vapor/12 hp (8.9 kW) Natural Gas
Applications. :
Stationary
Inlet Pressure (Maximum) :
T52B 5.0 psi (34.5 kPa);T52N 14.0” w.c. (3.45 kPa)
Mounting Position :
Vertical (outlet down) recommended
Diaphragm Material :
Hydrin
Description
IMPCO Model T52 , Single Stage Secondary Regulator , LPG Or Natural Gas. A Vacuum Lockoff, Mechanical Primer
Model T52
DESCRIPTION
The Model T52 is a single stage secondary regulator suitable for LPG Vapor or Natural Gas. Variations of the regulator include a vacuum lockoff, mechanical primer and new mounting tabs. The T52 regulator is completely rebuildable using an IMPCO repair kit.
SPECIFICATIONS
Fuel Type LPG Vapor or Natural Gas
Inlet Pressure(Maximum) 　
T52B 5.0 psi (34.5 kPa)
T52N 14.0” w.c. (3.45 kPa)
Outlet Pressure (Nominal) -0.5” w.c. (-0.12 kPa)
HP/kW Rating 　
T52B 40 hp (29.8 kW) LPG Vapor
T52B 25 hp (18.6 kW) Natural Gas
T52N 15 hp (11.2 kW) LPG Vapor
T52N 12 hp (8.9 kW) Natural Gas
Operating Temperature Range -40°F to +250°F (-40°C to +121°C)
Heating Chamber Source None Required
Mounting Position Vertical (outlet down) recommended. Horizontal position can be used when fuel contamination can be controlled with HD-5 or HD-10 specified LPG fuel.
Diaphragm Material Hydrin
Applications Mobile, stationary, and industrial
Certification UL (AU2317 & AU1502), Inquire for specific ECE approval
LPG Vapor Aluminum IMPCO T52 Low Pressure RegulatorLPG Vapor Aluminum IMPCO T52 Low Pressure RegulatorLPG Vapor Aluminum IMPCO T52 Low Pressure Regulator
