Specifications
Brand Name :
Hioso
Model Number :
HA7308C
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
2000pcs/month
Delivery Time :
3-10 working days
Packaging Details :
54X32X18 cm
Keywords :
FTTH OLT 8 PON EPON OLT
Description

Ftth 8 Ports Epon Olt 1u Rack Dual Power Supply Gigabit Olt For Fttx Solutions

Overview

HA7308C is a U rack type 8 SFP PON ports OLT.HA7308C works with HA7200 series ONU and ODN, to establish a passive optic network.

Feature

  • Distance can reach 20km under 1:32 split ratio
  • Each PON port can support 1.64 split ratio, total 512 ONUs access

Technical Specification

Parameter Specification
Operating wavelength 1310(RX) /1490(TX)
Optical power +2.5 ~ +7dBm
Receiving sensitivity -27dBm
Max distance 20km
Max splitter ratio 1:64
Capacity 8 SFP PON, each PON supports max 64pcs ONU, total 512pcs ONU
MAC 16k
Uplink port 4 SFP ports + 4 Combo(SFP/TP) ports
PON port 8 SFP 1000M fiber ports
Control port

1 10/100/1000M RJ45 port

1 Console(RJ45), to debug the device

1 USB port
MTBF 100,000 hours
EPON traits Support AES-128 encryption to each Logical Link Identifier
Support powerful OAM function, implement telnet management, maintenance and upgrade
Support auto discovery and auto register of ONU (real-time operation)
Network management Support GUI management based on SNMP
Support WEB management and Telnet GUI management based on CLI

Working Environment

Parameter Specification
Power Dual AC100~240V 50/60HZ
Power Consumption 35W
Operating temperature -10—55 C
Storage temperature -40—70 C
Humidity 5%--90% non-condensing
Dimension 440mm(length) * 260mm(width) * 44mm(height)

8 Ports Dual Power Supply Gigabit FTTH OLT For Fttx Solutions

8 Ports Dual Power Supply Gigabit FTTH OLT For Fttx Solutions

Company Introduction
HiOSO Technology Co., Ltd. was founded in 2002. Our main products include EPON systems, fiber optic media converters, CWDM system equipment, digital video optical transceivers, converter racks, single/multi-mode converters, PDH and fiber modems. Since the launch of our products in domestic market and international market, we have won a good reputation for our high quality products and sincere services. Our products are widely applied to network systems of Telecom, Radio and Television, Public Security and Bank industries.
