HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
Specifications
Brand Name :
Hioso
Model Number :
HA7308C-BP
Certification :
CE, RoHS, CCC
Place of Origin :
China, Guang dong
MOQ :
1
Price :
negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
negotiable
Delivery Time :
2-10 working days
Packaging Details :
40X35X15 cm
Product Name :
Epon olt
Type :
FTTH
Pon ports :
8 SFP Pon ports
Max Splitting Ratio :
1:64
Uplink :
4 SFP ports + 4 Combo(SFP/TP) ports
Warranty :
3 Years
Description


HA7308C Rack Type 8-PON OLT Dual power supply

FOWAY1510PFS 8 PORT POE SWITCH.pdf

HA7308C is a U rack type 8 SFP PON ports OLT.HA7308C works with HA7200 series ONU and ODN, to establish a passive optic network. The whole system supports 8-PON, 512 ONUs. It supports SNMP management and meets China Telecom EPON standards.


Feature

✔Supply 8 SFP PON ports, 4 1000M SFP ports, 4 Combo uplink ports

✔Each PON port support 1.64 split ratio, total 512 ONUs access

✔Distance can reach 20km under 1:32 split ratio

✔Support to work with HA400/HA7200 series ONUs to establish passive network

✔Support WEB and SNMP, integrate switching function

✔1U rack design, inside fan,better for heat dissipating and reliability operating

✔Apply for town,village fiber network and surveillance, apply for FTTX network,
to transmit IP phone, data,IPTV and other IP services access

Technical Specification

Parameter Specification
Operating wavelength 1310(RX) /1490(TX)
Optical power +2.5 ~ +7dBm
Receiving sensitivity -27dBm
Max distance 20km
Max splitter ratio 1:64
Capacity 8 SFP PON, each PON supports max 64pcs ONU, total 512pcs ONU
MAC 16k
Uplink port 4 SFP ports + 4 Combo(SFP/TP) ports
PON port 8 SFP 1000M fiber ports
Control port

1 10/100/1000M RJ45 port

1 Console(RJ45), to debug the device

1 USB port
MTBF 100,000 hours
EPON traits Support AES-128 encryption to each Logical Link Identifier
Support powerful OAM function, implement telnet management, maintenance and upgrade
Support auto discovery and auto register of ONU (real-time operation)
Network management Support GUI management based on SNMP
Support WEB management and Telnet GUI management based on CLI

Working Environment

Parameter Specification
Power Dual AC100~240V 50/60HZ
Power Consumption 35W
Operating temperature -10—55 C
Storage temperature -40—70 C
Humidity 5%--90% non-condensing
Dimension 440mm(length) * 260mm(width) * 44mm(height)

HiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONTHiOSO FTTH EPON OLT 8 PON OLT 4SFP GE 4 Combo Dual Power Supply Support Other Brand ONU ONT
