Industrial Heavy Duty Die Cutting Machine Adjustable PLC Touch Screen Controlled
Industrial Heavy Duty Die Cutting Machine Adjustable PLC Touch Screen Controlled
Specifications
Brand Name :
FINTEECH
Model Number :
FM-HK1500EFC
Certification :
CE
Place of Origin :
CHINA
MOQ :
1set
Packaging Details :
wooden case
Delivery Time :
20-30 days
Payment Terms :
TT/LC
Supply Ability :
10 sets per day
Condition :
New
Type :
Die-cutting Machine,Other,Paper Cutting Machine,General,corrugated pizza box making machine/printing machine
After-sales service provided :
Engineers available to service machinery overseas,Field installation,Free spare parts,Online support,commissioning and training
Warranty :
1 Year,one year,12 months,corrugated box die cut machine 1 year,2 Years
Computerized :
Yes,No
Application :
Commodity,Machinery & Hardware,Food,Apparel,Textiles
Product name :
Full automatic cross paper cutting machine a4,Flat Press Creasing Die Cutting Machine ML203,Carton small pneumatic stripping machine/Paper simple stripper machine,corrugated box die cut machine,cnc corrugated paper cardboard box die cutting machine
Packaging type :
Cartons,Film,Case,Bags,Bottles
Function :
Cardboard Automatic Die-cutting Machine,die cutting and creasing,For waste paper stripping,Flat Press Creasing Die Cutting
Description
Industrial Heavy Duty Die Cutting Machine
Product Attributes
Attribute Value
Condition New
Type Die-cutting Machine, Paper Cutting Machine, Corrugated Pizza Box Making Machine/Printing Machine
After-sales service Engineers available overseas, Field installation, Free spare parts, Online support, Commissioning and training
Warranty 1-2 Years
Computerized Yes/No options available
Application Commodity, Machinery & Hardware, Food, Apparel, Textiles
Product Name Full automatic cross paper cutting machine, Flat Press Creasing Die Cutting Machine, Corrugated box die cut machine, CNC corrugated paper cardboard box die cutting machine
Packaging type Cartons, Film, Case, Bags, Bottles
Function Cardboard Automatic Die-cutting, Die cutting and creasing, Waste paper stripping, Flat Press Creasing Die Cutting
Machine Details
Down Feeder System
  • High-precision down feeder with vacuum adsorption for scratch-free paperboard delivery
  • Pneumatic side push guide plates (right sides)
  • Electrically controlled paper feed roller
  • Precision paper pressing disc and front stop gauge with double sheet detection
  • Adjustable front block hook plate for cardboard bending compensation
  • Non-stop paper feeding step adjustment device
  • Fine adjustment for front/rear baffle positions based on gripper margin
  • Left/right side positioning push gauges for accurate cardboard alignment
  • High-quality dual-purpose vacuum pump
Die-Cutting Section
  • Nodular cast iron main body with upper platform and lower moving platform
  • Worm gear, worm and 40cr crankshaft
  • Rotating die-cutting plate and mould device
  • Torque limit overload protector
  • PLC touch screen controlled electric pressure regulation
  • Anodized aluminum alloy gripper bar system with adjustable structure
  • Main drive chain and intermittent divider
  • Synchronous belt and pulley drive system
  • Pneumatic clutch brake device for main drive
  • Air pressure detection with low pressure alarm
  • Central positioning system for fast, accurate plate changes
  • Air volume regulators for secure plate locking
  • Main motor drive
  • Centralized automatic oil supply system
  • Equipped with gas storage tank for stable air pressure
Stripping Section (4-Side Stripping)
  • Three-frame stripping mechanism
  • Center-line quick positioning installation for efficient plate replacement
Technical Specifications
Model FM-HK1500EFC
Maximum sheet size 1500×1100mm
Minimum sheet size 480×480mm
Maximum cutting size 1480×1080mm
Inner chase size 1510×1120mm
Maximum cutting pressure 400 Tons
Stock range E,B,C,A and AB Flute corrugated paper 1-8.5mm
Maximum speed 6000 s/h
Height of cutting rule 23.8mm
Total power required 30kw
Main motor wattage 15kw
Max. delivery pile height 1600mm (including wooden pallet)
Dimensions (L×W×H) 10490mm×5020mm×2850mm (including work platform)
Net Weight 29 Tons
Gripper margin 6-12mm
Min. gripper waste 10-18mm
Electric power 380V/50HZ/3PH
Mobile lower platen adjusting range ±1.5mm
Air requirement Pressure: 0.6-0.7Mpa, Flow rate: ≥0.37M³/min (Prepared by user)
