GYXTSV-12B1 Fiber Optic Wire 12 Core Single Mode G652D Outdoor Communication
GYXTSV-12B1 Fiber Optic Wire 12 Core Single Mode G652D Outdoor Communication
GYXTSV-12B1 Fiber Optic Wire 12 Core Single Mode G652D Outdoor Communication
GYXTSV-12B1 Fiber Optic Wire 12 Core Single Mode G652D Outdoor Communication
GYXTSV-12B1 Fiber Optic Wire 12 Core Single Mode G652D Outdoor Communication
GYXTSV-12B1 Fiber Optic Wire 12 Core Single Mode G652D Outdoor Communication
Specifications
Fiber Count :
12 Core
Delivery Time :
30 days
Price :
US $0.18 - 0.35 / Meter
Brand Name :
F.T
Structure :
Layer-stranded Loose Tube
MOQ :
1000
Color :
blue
Certification :
CE，VDE,SO 9001
Packaging Details :
Wooden Drum、cardboard box、wooden pallet
Fiber Grade :
G652D / B1
Fiber Mode :
Single Mode
Product Type :
Outdoor Fiber Optic Cable
Place of Origin :
china
Model Number :
Fibre Optic Cable
Supply Ability :
800–1500 kilometers per month
Payment Terms :
D/A,L/C,D/P,T/T,Western Union
Description
Fibre Optic Cable GYXTSV-12B1 12-core Single-mode G652D Outdoor Communication
GYXTSV-12B1 is a professional 12-core single-mode outdoor fiber optic cable engineered for long-distance and stable communication transmission. Adopting mature layer-stranded loose tube structure and integrated pressure-resistant design, this optical cable features low signal attenuation, strong tensile resistance and excellent environmental adaptability. Equipped with standard B1/G652D single-mode optical fiber, it ensures ultra-stable data transmission performance and long service life.
Different from ordinary ordinary optical cables with simple structure, GYXTSV-12B1 adds optimized waterproof and pressure-resistant structural design on the basis of traditional communication optical cables. The whole cable is compact in structure, not easy to deform, and effectively resorts external mechanical pressure and moisture erosion. It is widely applicable to outdoor overhead laying, pipeline communication, community network transformation, municipal engineering and other scenarios, being a mainstream reliable wiring solution for medium and long-distance communication projects.

Model & Structural Definition

Each letter and number of GYXTSV-12B1 corresponds to professional structural and performance parameters, meeting international communication industry standards, with clear positioning and strong pertinence in engineering applications:
  • G: General outdoor communication optical cable, dedicated for public communication network construction
  • Y: PE outer sheath, with excellent waterproof, anti-aging and weather resistance
  • X: Optimized loose tube stranded structure, uniform fiber stress, effectively avoiding signal loss caused by extrusion
  • T: Filled waterproof structure, fully filled with high-quality water-blocking ointment inside the cable core to block moisture penetration
  • S: Steel tape armored layer, enhances lateral pressure resistance and mechanical protection performance
  • V: Flame-retardant protective structure, effectively suppresses flame spread and improves construction safety
  • 12: 12-core optical fiber design, meeting medium-capacity network transmission requirements
  • B1: Standard G652D single-mode optical fiber, the most widely used fiber core for global communication networks
Item
Technical Parameters
Product Model
GYXTSV-12B1
Fiber Core Number
12 Cores
Fiber Type
G652D Single Mode (B1 Standard)
Working Wavelength
1310nm / 1550nm
Transmission Attenuation
≤0.36dB/km (1310nm); ≤0.22dB/km (1550nm)
Operating Temperature
-40℃ ~ +70℃
Tensile Strength
Long-term: ≥1000N; Short-term: ≥1500N
Lateral Pressure Resistance
≥1000N/100mm
Bending Radius
Static: 10×Cable Diameter; Dynamic: 20×Cable Diameter
Outer Sheath Material
High-Density PE Flame-Retardant Material
Waterproof Grade
Full Water-Blocking Structure, Outdoor Waterproof Level
Service Life
25 Years Under Normal Working Conditions
Execution Standard
ITU-T & International Communication Industry Standard

Wide Application Scenarios

With balanced mechanical performance, stable transmission capacity and strong environmental adaptability, GYXTSV-12B1 fiber optic cable is the preferred wiring product for medium and long-distance outdoor communication projects, widely used in the following fields:
  • Municipal public communication network construction and renovation
  • Community, campus and park network wiring engineering
  • Road, bridge and tunnel communication transmission system
  • Industrial park and remote base station signal transmission
  • Pipeline buried laying and overhead outdoor communication lines
  • Enterprise private network and medium-distance data transmission engineering
