Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Specifications
Brand Name :
Gofun
Model Number :
GFM-CDF-50
Certification :
CE/ISO9001
Place of Origin :
Shanghai, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
T/T,Western Union,L/C,Visa
Supply Ability :
20 sets per year
Packaging Details :
International standard packaging for shipping
Warranty :
1 Year
After-sales service provided :
Engineers available to service machinery overseas
Voltage :
220/380/440V, according to customers
Type :
Dryer
Material :
Food standard SUS 304, 316, accourding to customer
Capacity :
1000kg/hour according to customers
Application :
Agricultural and sideline products, seafood, fruits and vegetables, dried fruits
Product name :
Heat Pump Full-Effect Dehumidifier
End products :
Agricultural and sideline products, seafood, dried fruits, etc.
Special process :
Integrated structural design,With high temperature hot air circulation drying
Description
Heat Pump Full-Effect Dehumidifier
Product Features
This product combines a high-temperature heat pump with a desiccant rotor dehumidifier, enabling continuous maintenance of ultra-low relative humidity under normal temperature conditions.
Adsorption Zone Operation
Moist, hot air from inside the drying chamber first passes through the evaporator of the dehumidification compressor, which lowers the air temperature while increasing the moisture content per unit volume. The air then enters the adsorption zone of the desiccant rotor, where dehumidification occurs, significantly reducing the air's relative humidity.
After dehumidification, the air flows through the condenser of the heating compressor, which raises its temperature while further reducing relative humidity. This conditioned air is then sent back into the drying chamber to process the materials inside.
Regeneration Zone Operation
External air is rapidly heated by the condenser of the dehumidification compressor. As this high-temperature air passes through the regeneration zone of the desiccant rotor, water molecules are quickly released from the rotor under the influence of the high-temperature environment.
The moisture-laden air then passes through the evaporator of the heating compressor, where waste heat is recovered, before being discharged to the outside. This process achieves the goal of rapid dehydration and regeneration of the desiccant rotor.

Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier

Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier


Dried Material Applications
Widely used in agricultural and sideline products, Chinese herbal medicines, aquatic products, wood, tobacco, industrial and other hot air drying processing fields.

Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier

Technical Advantages

Most aquatic products dryed temperature is below 30℃ . The full-effect dehumidifier is an advanced combined drying system.Controllable temperature between 10-30 ℃. It is using the negative pressure fan to increase the circulating air volume and wind speed in the sealed insulation room.Avoid water vapor stay on the surface of the material.The dryer units will fed the dry air into the drying room on the working time.To make full contact with the mateial .and to take away the material's steam by the circulating air.water vapor is condensed and filtered by the unit and discharged to the outside of the house.Then condensed the steam and filtered by the dehumidifier and to drained out of the drying room.This model integrates heat pump technology, electric field technology and rotary-wheel dehumidifier technology.The drying process reduces energy loss, which is 4-5 times that of the conditional heat pump dehumidifier, Reduced the operating costs largely.

Technical Specifications
Unit Model Compressor Power Power Input (KW) Heating Power (KW) Rated Temperature

Rated

Voltage (V)

Rated Ameter (A)

 Environmental Temp (℃)

Working Fluid

(KGS)

 Sound Level (DB)

Machine Size

(MM)

 Weight (KG
GFM-CDF-50 14P 13.5 18 80/85 380 30 5-45 8.5 55 2300x1650x1714 720
High Temperature Heat Pump System Principle
The high temperature heat pump consists of compressor, condenser, throttling device and evaporator. The refrigerant absorbs air heat from the evaporator, transforming from low pressure liquid to steam, then pressurized into high temperature steam by the compressor. In the condenser, the refrigerant releases heat and condenses into high pressure liquid. The throttling device reduces pressure and temperature, completing the cycle that transfers low temperature heat to high temperature medium.
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Process Display
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Company Information
Gofun Company offers comprehensive turnkey solutions for tomato paste production lines and processing/packaging lines for various fruits including apple, pear, peach, mango, and apricot. Our machines have been successfully exported worldwide to Asia, Africa, South America, Europe, and North America.
We are dedicated to developing exceptional food machinery and contributing to the global agricultural industry, fostering mutually beneficial relationships with partners worldwide.
Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier Large Capacity 1000kg/hour CE/ISO9001 Certified Fruit Drying Machine with Low Temperature Drying (10-30℃) and Heat Pump Dehumidifier
Our Services
  • Technical support
  • Marketing suggestion
  • Final packing suggestion and design
  • Factory building and design
  • Oversea technical support
  • Oversea equipment maintenance
  • English speaking engineers available
