Continuous Casting Free Forged 20CrMnTi Roller Shaft Steel Mill Equipment Used
Continuous Casting Free Forged 20CrMnTi Roller Shaft Steel Mill Equipment Used
Continuous Casting Free Forged 20CrMnTi Roller Shaft Steel Mill Equipment Used
Continuous Casting Free Forged 20CrMnTi Roller Shaft Steel Mill Equipment Used
Continuous Casting Free Forged 20CrMnTi Roller Shaft Steel Mill Equipment Used
Continuous Casting Free Forged 20CrMnTi Roller Shaft Steel Mill Equipment Used
Specifications
Brand Name :
Tian Gong
Certification :
ISO9001, ISO14001,ISO45001
Place of Origin :
Changzhou, China
MOQ :
1
Price :
USD500-USD1000/piece
Payment Terms :
T/T
Supply Ability :
56000 Tons per year
Delivery Time :
30days
Packaging Details :
Pallet
Surface Treatment :
Heat Treatment，Removal of oxide scale or Customized
Size :
Customized
Material :
42CrMo4, 20CrMnTi or Customized
Weight :
100 KG-7 TON
Type :
Free Forging
Application :
Continuous Casting and Steel Mill Equipment
Packing :
Pallet or Customized
Shape :
Customizable
Durability :
Long time
Description

Free Forged Roller Shaft for Continuous Casting and Steel Mill Equipment. Our free forged roller shafts are purpose-built to endure the extreme mechanical and thermal stresses found in continuous casting lines, hot rolling mills, and other steel processing equipment. Manufactured using high-strength alloy and carbon steels, each shaft is precision-forged to ensure superior fatigue resistance, dimensional accuracy, and long operational life under heavy loads and cyclic conditions.

Key Features:

  • Material Options: 42CrMo, 45#, and other custom alloy steels offering excellent toughness, hardenability, and thermal fatigue resistance.

  • Forging Method: Open-die forging (free forging) for dense, refined grain structure and defect-free integrity, especially critical in high-load roller applications.

  • Size Capabilities: Large-diameter, extra-long shafts suitable for various roller configurations—work rolls, support rolls, intermediate rolls, and pinch rolls.

Applications:

  • Roller shafts for continuous casting machines

  • Support and drive rolls in hot and cold rolling mills

  • Roller components in reheating furnaces and billet handling systems

Item Details
Product Name Free Forged Roller Shaft for Continuous Casting and Steel Mill Equipment
Material Grades - Alloy steels: 42CrMo - Carbon steels: 45# - Excellent tensile strength, fatigue resistance, and thermal stability for high-load and high-temperature operations in rolling mills
Forging Equipment - Hydraulic hammers: 5T / 8T / 12T - 3600T open-die forging press for long, large-diameter roller shaft forgings - Capable of forming stepped shafts with journals, necks, and custom drive end profiles
Manufacturing Process Hot Forging → Heat Treatment (Quenching + Tempering / Normalizing) → Ultrasonic Testing → Rough / Semi-Finish Machining → Final Dimensional & Surface Inspection
Forging Ratio ≥ 3.0 — Ensures directional grain flow along the shaft axis for improved impact toughness, torsional strength, and long-term reliability under cyclic rolling loads
Applications - Roller shafts in continuous casting machines and billet handling systems - Work rolls, backup rolls, and intermediate rolls in hot and cold strip rolling mills - Roller components for steel processing, reheat furnaces, and coil transport equipment
Heat Treatment Options - Quenched + Tempered for enhanced strength, hardness, and wear resistance in dynamic rolling environments - Normalizing for uniform microstructure and improved machinability - Optional stress-relief annealing to reduce residual stress prior to finish machining
Testing & Inspection - Chemical: Alloy verification by spectrometer - Mechanical: Tensile strength, yield strength, hardness, and Charpy impact tests (longitudinal & transverse) - Ultrasonic Testing (UT): 100% internal flaw detection along the shaft length - Dimensional: Concentricity, straightness, diameter tolerance, and surface finish control
Value-Added Services - Pre-machining of journals, keyways, shoulders, and coupling interfaces - Complete material traceability: heat number, batch number, mechanical and NDT reports (MTC)
