Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Specifications
Brand Name :
Forsentek
Model Number :
FL51
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Payment Terms :
T/T,Western Union or Paypal
Supply Ability :
2500pcs/month
Delivery Time :
3~25 working days
Packaging Details :
Carton
Usage :
Force measurement transducer
Type :
Tension compression load cell
Output :
Analog Sensor
Capacity :
1KN 2KN 5KN 10KN 20KN
Threaded rod :
M12
Description

Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Features

  • CE certified
  • Stainless steel construction,in-line structure
  • M12 threaded bolts on both sides,easy to install
  • Tension compression force measurement

Applications

  • Axial force measurement
  • Air cylinder pull push force measurement
  • Welding force control
  • Testing machine
  • Assembly line

Specifications

Capacity1KN 2KN 5KN 10KN 20KN
Rated output1.5mV/V
Excitation3-15V
Zero balance±0.05mV/V
Nonlinearity±0.5% R.O.
Hysteresis±0.5% R.O.
Nonrepeatability±0.2% R.O.
Creep(5min)±0.1% R.O.
Safe overload150% F.S.
Ultimate overload200% F.S.
Compensated temperature-10...+40oC
Operating temperature-20...+60oC
Temperature shift zero±0.02% R.O./oC
Temperature shift span±0.02% R.O./oC
Input resistance385±30 ohms
Output resistance350±5 ohms
Insulation resistance>5000M ohms
Ingress protectionIP66
Material of elementStainless steel
CableØ5*2000mm 4-core shielded
Wiring code

Red-Excitation+ Black-Excitation-
Green-Signal+ White-Signal-


Tension compression force sensor with CE certificate

Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Tension and compression force sensor FL51 is produced based on strain gauge technology with -20~20mV analog output.-5~5V/0-10V/4-20mA output is achievable through external signal conditioner.
Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN
Dimensions
Tension and compression force sensor 20KN 10KN 5KN 2KN 1KN

Click here to download datasheet
