Specifications
Dimensions :
63.2mm * 27.5mm * 4.3mm
Operating Voltage :
3.3V
Place of Origin :
China
MOQ :
1 piece
Payment Terms :
T/T,L/C,Credit card,Cash
Product Name :
128x32 LCD Display Graphic COG FSTN 12832 LCD Module with 28 Pin Parallel or Serial Interface
Display Type :
Graphic LCD Display
Brand Name :
Formike
Interface :
28 Pin, Parallel or Serial
Backlight Color :
Black display dot on white background with blue backlight
Viewing Angle :
6 O'clock
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Packaging Details :
Tray + Inner Box + Carton
Controller :
ST7565R
Backlight :
LED
LCD Type :
Transflective Positive
Model Number :
WG1203X6FSB6G
Supply Ability :
5000000000 pieces/year
Display Format :
128x32 Dots
Operating Temperature :
-10°C to 60°C
Display Mode :
FSTN
Description

128x32 LCD Display Graphic COG FSTN 12832 LCD Module with 28 Pin Parallel or Serial Interface

LCD Name 128x32 LCD Display Graphic COG FSTN 12832 LCD Module with 28 Pin Parallel or Serial Interface

Display Format

128 X 32 Dots

Display Mode

FSTN, Positive, Transflective

LCD Color

Display dot : Black
Background: White

Driver IC

ST7565R

Outline Dimension

63.0x27.5x4.3mm

Viewing Area

59.0x17.5mm

Viewing Direction

6 O’clock

Interface Input Data

Parallel or Serial

Backlight

Blue LED backlight

Driving Method

1/33 Duty, 1/6 Bias

Working Temp.

 -10℃~+60℃

Storage Temp.

-20℃~+70℃

Graphic COG FSTN 128x32 LCD Display 12832 Character Module With 28 Pin Parallel Or Serial InterfaceGraphic COG FSTN 128x32 LCD Display 12832 Character Module With 28 Pin Parallel Or Serial Interface

Graphic COG FSTN 128x32 LCD Display 12832 Character Module With 28 Pin Parallel Or Serial Interface Graphic COG FSTN 128x32 LCD Display 12832 Character Module With 28 Pin Parallel Or Serial Interface
Graphic COG FSTN 128x32 LCD Display 12832 Character Module With 28 Pin Parallel Or Serial Interface
