Specifications
Controller :
SBN1661G
Display Mode :
STN
Supply Ability :
5000000000 pieces/year
Product Name :
STN COB LCD Graphic Display 128x32 LCD Module With 20 Pin 8-BIT 6800 8080 MPU Interface
Display Type :
Graphic LCD Display Module
Viewing Angle :
6 O'clock
Packaging Details :
Tray + Inner Box + Carton
Payment Terms :
T/T,L/C,Credit card,Cash
Display Format :
128x32 Dots
Operating Temperature :
-20°C to 70°C
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Backlight Color :
Usually Y-G or Blue or Gray
Brand Name :
Formike
Dimensions :
225.0mm * 60.8mm * 12.5mm
Model Number :
WG1203B5
MOQ :
1 piece
Operating Voltage :
3.3V / 5V
Backlight :
LED
Place of Origin :
China
Interface :
20 Pin, 8-bit 6800/8080 MPU
Description

STN COB LCD Graphic Display 128x32 LCD Module With 20 Pin 8-BIT 6800 8080 MPU Interface

STN COB Graphic 128x32 LCD Display Module With 20 Pin 8 BIT 6800 8080 MPU Interface

Product Specification
LCD Name STN COB LCD Graphic Display 128x32 LCD Module With 20 Pin 8-BIT 6800 8080 MPU Interface
Display Format

128*32 Dots
Module Size 225.0mm×60.8mm×12.5mm
View Area 185.0mm×41.5mm
Active Area 179.16mmx38.60mm
Dot Size 1.36mm×1.16mm
Dot Pitch 1.40mm×1.20mm
IC SBN1661G
Interface 20 Pin, 8-bit 6800 / 8080 MPU interface enabled
Driving Method 1/32 Duty, 1/6 Bias
Viewing Direction 6 O’clock
Operating Temperature -20℃~+70℃
Storage Temperature -30℃~+80℃
Different series type LCD mode for you to choose
No. Part Number LCD Type Backlight Color Font Color Background Color Voltage
1 WG1203B5SBY6B-A1 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 5V
2 WG1203B5SBY6B-A2 STN Y-G Positive Yellow Green Color Black Color Yellow Green Color 3.3V
3 WG1203B5SGW6B-A1 STN Negative Blue White Color White Color Blue Color 5V
4 WG1203B5SGW6B-A2 STN Negative Blue White Color White Color Blue Color 3.3V
5 WG1203B5SKW6B-A1 STN GREY Positive White Color Black Color Grey Color 5V
6 WG1203B5SKW6B-A2 STN GREY Positive White Color Black Color Grey Color 3.3V
