Specifications
Display Format :
240*64 Dots
Controller :
T6963C
Supply Ability :
5000000000 pieces/year
Product Name :
240x64 LCD Display 24064 T6963C Graphic LCD LCM
MOQ :
1 piece
Operating Temperature :
-20°C to 70°C
Backlight :
LED
Model Number :
WG2406B0
Display Mode :
STN
Dimensions :
180.0mm * 65.0mm * 12.5mm
Brand Name :
Formike
Place of Origin :
China
Interface :
22 Pin, 8-bit 8080 MPU
Display Type :
Graphic LCD Display
Operating Voltage :
5V
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Packaging Details :
Tray + Inner Box + Carton
Backlight Color :
Usually Y-G or Blue or Gray
Payment Terms :
T/T,L/C,Credit card,Cash
Viewing Angle :
6 O'clock
Description

240x64 LCD Display 24064 T6963C Graphic LCD LCM

22 Pin 24064 240x64 LCD Display T6963C Graphic LCD LCM Blue Or Gray

Product Specification
LCD Name240x64 LCD Display 24064 T6963C Graphic LCD LCM
Display Format

240*64 Dots

Module Size180.0mm×65.0mm×12.5mm
View Area132.0mm×39.0mm
Active Area127.16mmx33.88mm
Dot Size0.49mm×0.49mm
Dot Pitch0.53mm×0.53mm
ICT6963C
Interface22 Pin, 8-bit 8080 interface enabled
Driving Method 1/64 Duty, 1/9 Bias
Viewing Direction6 O’clock
Operating Temperature-20℃~+70℃
Storage Temperature-30℃~+80℃
Different series type LCD mode for you to choose
No.Part Number LCD Type Backlight ColorFont Color Background Color Voltage
1WG2406B0SBY6B-A1STN Y-G PositiveYellow Green Color Black ColorYellow Green Color5V
3WG2406B0SGW6B-A1STN Negative BlueWhite ColorWhite ColorBlue Color5V
5WG2406B0SKW6B-A1STN GREY PositiveWhite Color Black ColorGrey Color 5V
