Specifications
Place of Origin :
China
Display Size :
5.7 inch
Dimensions :
144.0mm x 104.60mm x 14.45mm
Resolution :
320 x 240
Supply Voltage :
3.3V
Brightness :
650cd/m2
MOQ :
1 piece
Product Name :
5.7 TFT LCD Display 320x240 TFT Panel With Touch Screen And High Brightness
Interface :
33 Pin, 18 BIT RGB
Viewing Angle :
6 O'Clock
Brand Name :
Formike
Model Number :
KWH057DF10-F02 V.1
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Touch Screen :
With resistive touch screen
Operating Temperature :
-20°C to 70°C
Packaging Details :
Tray + Inner Box + Carton
Supply Ability :
5000000000 pieces/year
Display Type :
5.7 Inch TFT LCD Display
Payment Terms :
T/T,L/C,Credit card,Cash
Color :
Color
Description

5.7 TFT LCD Display 320x240 TFT Panel With Touch Screen And High Brightness

High Brightness 5.7 TFT LCD Display 320x240 colour TFT Panel Touch Screen ODM

Product Name 5.7 TFT LCD Display 320x240 TFT Panel With Touch Screen And High Brightness
LCD Size 5.7 Inch TFT LCD Display Module
Display Mode Transmissive
Resolution 320x240
Outline Dimension (mm) 144.00x104.60x14.45
Active Area (mm) 115.20x86.40
Viewing Direction 6 O'Clock
Interface RGB Interface, 33 Pin
Brightness (Cd/m2) 650
Contrast Ratio 450:1
Backlight 30 White LED

Backlight Supply

(Current/Voltage)

 200mA 9.6V
Touch Screen With Resistive Touch Screen

* KWH057DF10-F02 V.1 is a Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight, resistive touch screen.

* It is 320x240 resolution TFT LCD module.

* Backlight with different brightness options from 500 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
