Specifications
Color :
Color
Brand Name :
Formike
Display Type :
IPS TFT Display
Interface :
4W SPI
Supply Voltage :
3.0V
Packaging Details :
Tray + Inner Box + Carton
Product Name :
1.54 Inch LCD Module SPI TFT 240x240 Display
Resolution :
240 x 240
Viewing Angle :
All
Supply Ability :
5000000000 pieces/year
Place of Origin :
China
Operating Temperature :
-20°C to 70°C
MOQ :
1 piece
Payment Terms :
T/T, L/C, Credit card, Cash
Dimensions :
31.5mm x 35.0mm x 2.3mm
Controller Ic :
ST7789H2
Model Number :
KWH0154DF03-F01
Display Size :
1.54 inch
Delivery Time :
In Stock: 3~8 working days. No Stock: LCD / LCM / OLED Products——5~8 weeks;
Description

1.54 Inch LCD Module SPI TFT 240x240 Display

4W TFT LCD Display Screen Module SPI ST7789H2 240x240 1.54 Inch 400cd/m2

LCD Name 1.54 Inch LCD Module SPI TFT 240x240 Display

LCD Size

1.54 inch LCD Module

Resolution

240(RGB)X240 Resolution

Color

262K

Contrast Ratio

500:1

Outline Dimension

31.50 x 35.00 x 2.30mm

Active Area(HxV mm)

27.72 x 27.72mm

Viewing Direction

Free

Interface

4W SPI, 24pins

Backlight

3 White LED In parallel

Brightness

400cd/m2

IC Driver

ST7789H2

Backlight Supply Current/Voltage

60mA,3.2V

* KWH0154DF03-F01 is a small Transmissive type color active matrix liquid crystal display (LCD).

* It is composed of a TFT LCD panel, driver IC, FPC, backlight.

* It is 240x240 resolution TFT LCD module.

* Backlight with different brightness options from 250 - 1500cd/m2 are available.

* Specific touch panel can be designed & customized.

* RoHS & REACH compliant.

* If you can't find a suitable one, contact us to get a recommendation.
