Specifications
Brand Name :
PAISHUN
Model Number :
4mmx8mm, 6mmx13mm ect
Certification :
ISO9001, IATF14949, ROHS ect.
Place of Origin :
CHINA
MOQ :
5000meters
Price :
0.45USD/meter
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
300000meters/month
Delivery Time :
20days
Packaging Details :
well packed by high quality braided straps for export.
Type :
hose for petroleum or water air
Brand :
Paishun
Sizes :
3/16"~2"
Inner Tube :
NBR/SBR
Cover :
braided nylon fiber
working pressure :
10bar / 20bar
Length :
50meters / 100meters
Temperature :
-30℃ to 100℃
Color :
black
MOQ :
5000meters
Description

Flexible Outer Fiber Braided Rubber Hose 300 PSI for Petroleum Water Air
Outer Braided Rubber Hose
Structure: Tube: Pure rubber tube. It can be designed as to be heat, oil, acid, alkaline and wear resistant hoses according to the requirements of application.
Reinforcement: High tensile polyester fiber braided.
Outer cover: Stainless steel wire, or Aluminium wire, or cotton threads, or polyester fiber lines, which is used for strengthening pressure or protection.
Temperature: -40ºC - +150ºC, customized according to application.
Tube color: Black, etc.
Application: Mainly used for conveying of air, insert gas and water in mining, construction, engineering, shipbuilding, steel production etc.
Standard length: 50m, 100m.


Specification of the inner hose:

Item code Inner Diameter Outer Diameter Working Pressure Burst Pressure Length Measurement Weight
inch mm mm bar psi bar psi m cbm/roll kg/m
PRA-06 1/4" 6 13 20 300 60 900 100 0.0256 0.17
PRA-08 5/16" 8 15 20 300 60 900 100 0.0271 0.22
PRA-10 3/8" 10 17 20 60 60 900 100 0.036 0.26
PRA-13 1/2" 13 22 20 300 60 900 100 0.0634 0.4
PRA-16 5/8" 16 25 20 300 60 900 50 0.1095 0.45
PRA-19 3/4" 19 29 20 300 60 900 50 0.146 0.7
PRA-25 1" 25 36 20 300 60 900 50 0.171 0.85

Note: The inner hose can also be Pure rubber tube without fiber braided reinforcement.
If the specifications you need are not in the list, please offer your specification parameters or operating requirements. We'll check and customize.
