Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi
Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi
Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi
Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi
Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi
Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi
Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi
Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi
Specifications
Brand Name :
PASSION
Model Number :
ID 3/8"
Certification :
ISO 9001-2008, CE
Place of Origin :
Zhejiang China
MOQ :
200 pcs
Price :
Negotiated
Payment Terms :
Western Union, MoneyGram, L/C, T/T, PayPal
Supply Ability :
100,000 pcs per month
Delivery Time :
30 days for 20' FCL
Packaging Details :
Well packed by transparent opp film and wooden pallet, or as your request.
Material :
SBR or EPDM
Color :
Black, Red, etc
Fitting :
1/4" BSP or NPT fittings
Temperature :
-30℃ - +80℃
Length :
25ft, 50ft
Market :
UK, USA, Canada
Inner diameter :
10mm
Description

ID 3/8" Rubber Air Line with BSP or NPT fittings, BP 900 psi and BP 1200 psi

Construction: Tube: NR& SBR synthetic rubber.

Reinforcement: High tensile polyester fiber braided.

Cover: NR & SBR synthetic rubber.

Temperature: -30℃ - +80℃

Color: Red, Yellow, Blue, Green, Orange, Black, etc.

Application: Mainly used for conveying of air, insert gas and water in mining, construction, engineering, shipbuilding, steel production etc.

Standard length: 25ft (7.6m), 50ft(15m)

Specification of hose:

Inner Diameter

Outer Diameter

Working Pressure

Burst Pressure

Length

Weight

inch

mm

mm

bar

psi

bar

psi

Ft/pc

kg/pc

3/8"

10

17

20

300

60

900

25

2.26

3/8"

10

17

20

300

60

900

50

4.40

3/8"

10

17

20

300

80

1200

25

2.29

3/8"

10

17

20

300

80

1200

50

4.43

Specification of fittings:

Brass 1/4” Male NPT fittings on both ends of the hose.

Brass 1/4” Female BSP fittings on both ends of the hose.

Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi

Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi

Red Rubber Air Hose with BSP Or NPT Fittings , Rubber Air Line BP 900 / 1200 Psi

Competitive Advantage:

PASSION® Rubber air hose assembly, is popular in UK (bsp fitting), USA and Canada (NPT fitting), made of non-recycled rubber, according to ISO-2398 standard.

Hangzhou Paishun can crimp the specified fittings and quick released coupling on the rubber air hose.

If you have some special request of size, Hangzhou Paishun can also customize for you.
