Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Specifications
Brand Name :
Ankuai Intelligent Tech Inc.
Model Number :
AK800DC
Certification :
ISO9001, CE Certificate
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30000 sets per Month
Delivery Time :
3 Work days for sample
Packaging Details :
Regular package way with carton
Cabinet Dimension :
291*246*299mm
Motor :
DC Motor
Motor Power :
200W
Opening and closing times :
12-18m/min
Load-bearing capacity :
Max 800kg
Cabinet Color :
Black and Grey
Working Temperature :
-30°C~80°C
Remote Control :
30m~50m
Direction :
Bi-Direction
Boom Type :
Telescopic, Boom, Floding, etc.
Warranty :
1-year gurantee except for artificial damage
Delivery time :
3 work days for sample
Description
Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions
Product Specifications
Application
Sliding Gate
Place of Origin
Guangdong, China
Brand Name
ANKUAI
Product name
Opener Gate
Product model
AK800DC
Size
291*246*299mm
Opening and closing times
12-18m/min
Voltage
AC220V
Motor
DC Motor
Motor Power
200W
IP Rating
IP54
Remote control distance
30m~50m
Product Features
Chracteristics
  • Soft start and slow stop.
  • Automatic reverses after encountering obstacles.
  • Motor output force, stall force, slow stop distance are adjustable.
  • Automatic close with waiting time adjustable.
  • Partial opening for pedestrian passes.

Electrical Features
  • Exclusive Adaptability: Exclusively designed and manufactured for use with a single sliding gate, and only supports usage scenarios specified in the documentation, ensuring precise alignment between product functions and usage requirements.
  • Compatibility with Optional Safety Accessories: Can be equipped with infrared photocells for installation according to actual needs to detect obstructions, further expanding safety protection functions and adapting to scenarios with different safety requirements.
  • Emergency Operation Support: Equipped with a manual opening operation method. In case of sudden emergencies, the gate can be opened and closed normally through manual operation, enhancing operational flexibility and emergency support capabilities.
Safety Mechanisms
  • Electrical Safety Provisions
    • It's clearly required that the input voltage matches the gate opener's supply voltage to prevent equipment breakdown or safety incidents due to voltage mismatch.
    • The power cable must mandatorily be connected to a weatherproof power outlet with Residual Current Device (RCD) protection, installed by a qualified electrician. This ensures dual electrical safety protection and is fit for damp environments like outdoor spaces.
  • Safety Controls for Installation and Maintenance
    • Before installation and maintenance, the power plug must be disconnected. Also, tasks like wiring, electrical circuit changes, and voltage adjustment are only for qualified electricians, cutting off the electric shock risk at the operation source.
    • Before motor installation, a Gate End Catch and a Gate Stop should be fixed at each rail end to stop the gate from derailing. At the same time, potential gate dangers and exposed pinch points must be removed ahead of time to ensure safety during installation and equipment operation.
  • Usage Scenario and Operational Safety Restrictions
    • Installing in explosive atmospheres or flood - prone areas is forbidden to avoid safety accidents from extreme environments. Besides, the equipment is only for a single sliding gate, eliminating safety risks in non - compliant cases.
  • After-sales and Maintenance Safety Specifications
    • Only original parts shall be used for maintenance or repair operations. The company disclaims all responsibility for the safety and correct operation of the automation system if components from other suppliers are used.
    • Modification of automation components is not allowed unless explicitly authorized by the company; users shall not attempt to perform any maintenance or repair work on the product and must always seek assistance from qualified personnel.
  • Warranty and Environmental Protection Tips
    • Any act not expressly permitted in these instructions is prohibited and will void the warranty.
    • All packaging materials (plastic, cardboard, polystyrene, etc.) shall be disposed of in accordance with current guidelines, and plastic bags and polystyrene must be kept out of children’s reach.
  • Documentation Retention Requirement: These instructions shall be saved for future reference.
Technical Specifications
Voltage DC24V
Drive DC Motor
Motor Power Consumption 200W
Working Temperature -30°C ~80°C
Humidity ≤90%
Remote Control Distance ≤30m
IP Rating IP54
Key Functions
  • Automated Sliding Operation
    Enables hands-free, smooth sliding of single gates with stable motor performance, reducing manual effort.
  • Emergency Manual Override
    Allows manual gate opening/closing during power outages or system malfunctions for uninterrupted access.
  • Obstruction Detection Compatibility
    Works with infrared photocells to sense obstacles (e.g., people, objects) and stop/reverse gate movement, preventing collisions.
  • Safe Power Management
    Supports connection to RCD-protected outlets; auto-powers down during maintenance to avoid electrical hazards.
  • Remote Control Integration
    Pairs with dedicated remotes for convenient operation from a distance; prevents unauthorized access via child-safe design.
  • Track Deviation Prevention
    Compatible with gate end catches and stops to keep the gate on-track, avoiding derailment and equipment damage.
Applications
  • Residential Properties
    Ideal for driveways of houses, villas, or townhomes—provides secure, convenient access control for homeowners.
  • Commercial Premises
    Used in parking lots, retail store back entrances, or office compound gates to manage vehicle/pedestrian flow efficiently.
  • Industrial Facilities
    Suitable for warehouse loading docks, factory perimeter gates, or logistics yards—handles heavy-duty sliding gates for secure asset protection.
  • Institutional Areas
    Applied in schools, hospitals, or government campus gates to regulate entry/exit and ensure safety for staff, students, or visitors.
  • Recreational Sites
    Installed at community parks, sports complexes, or resort entrances—offers easy access while maintaining site security.

Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions

Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions

Smart AK800DC Automatic Door Opener for Commercial Spaces: Remote, WiFi App & Infrared Sensing Functions


Frequently Asked Questions
What is your company's strength in this field?

We are one of the leaders in this field with ISO certification, 50,000+ square meter facility, 130+ national patents, strong R&D team with 30+ professionals, and over 300 assembly workers. We have 76 distributors in China and 50+ worldwide.

How do you guarantee product quality?

We have ISO9001 and CE certifications and are committed to providing the best product quality possible to our customers.

Do you provide OEM service?

Yes, we offer custom barrier gates according to your needs, including logo printing and custom packaging.

What is the lead time for standard items?

1-50 sets: 5 working days; 50-100 sets: 7 working days; 100-500 sets: 15 working days. Custom items may require 3-10 additional days.

What warranty and after-sales service do you provide?

We offer 1-year quality guarantee with professional engineering support and 24-hour response time for inquiries.
