Specifications
Place of Origin :
China
Brand Name :
ISUZU
Certification :
ISO9000
Model Number :
CLW
MOQ :
1
Price :
15000-35000 per unit
Packaging Details :
Nude
Delivery Time :
65 working days after deposit
Payment Terms :
50% Deposit,Balance should be paid before ship out
Supply Ability :
500PCS/Week
Model NO. :
ISUZU
Emission Standard :
Euro 4
Hoesrpower :
251-350hp
Payload :
20T
Fuel :
Diesel
Transmission Type :
Manual
Drive Wheel :
4x2
Condition :
New
Transport Package :
Naked
Specification :
7200*2000*3100 mm
Trademark :
ISUZU
Origin :
China
HS Code :
8701909000
Customization :
Available
Type :
H
Shipping Cost :
Contact the supplier about freight and estimated delivery time.
  :
Support payments in USD
Secure payments :
Every payment you make on Made-in-China.com is protected by the platform.
Refund policy :
Claim a refund if your order doesn't ship, is missing, or arrives with product issues.
Manufacture :
Chengli Special Automobile Co.,Ltd
Name :
Aerial Platform Truck
Description

ISUZU Bucket Hydrulic Lift Working Ladder Lifting Pickup Type Aerial Work Truck



Aerial working platform ( also called aerial platform truck , aerial lift , hydraulic beam lifter , aerial boom lift , bucket truck , telescopic platform , boom lift , overhead working truck , hydraulic aerial cage , sky lift ) Is ideal for maintenance of traffic lights , street lights , landscaping trees , Cleaning / setting signboard and other high aerial works .

Aerial work vehicles with telescopic arm can be reach to 22 m , Widely used in municipal , electricity , street lamps , advertising , communications , photography , gardens , shipbuilding , transportation , terminals , airport ports , rescue , large industrial and mining enterprises and other industries installation and maintenance operations .

Technical date:
Main specification
Product model and name 28m Aerial Working Truck For Sale
Gross weight(Kg) 7300 Drive type 4X2,LHD
Curb weight(Kg) 6975 Overall dimension(mm) 7650X1980X3100
Approach/departure angle(°) 19/13 Cab seats 3+3
Axle No. 2 Front/rear hang(mm) 1032/2118
Axle load(Kg) 2920/4380 Wheelbase(mm) 3300
Max speed(Km/h) 95

Chassis specification
Chassis model EQ1060GLJ Manufacturer Dongfeng Motor Co., Ltd
Brand name Dongfeng Dimension(mm) 5845×1900×2220
Tyre specification 7.00-16 Tire No. 6+1(One spare tire)
8 8/9+5 Front track base(mm) 1506
Fuel type Diesel Rear track base(mm) 1466
Emission standard Euro III Transmission 5 forward gear
Cab Double row,6 person allowed with power steering, optional to fix A/C
Engine model Engine manufacturer Displacement(ml) Power(Kw)
CY4102-C3F Dongfeng Diesel Engine Co.,Ltd 3856 95(70HP)
Upper part
Working height 15.6M meters Control Electronic
Maximum operating range 7.5m maximum lifting height 28 meters
Rotation speed 0-2r / min Rotation angle: 360 degrees
Hydraulic landing legs 4pics Working bucket max loading 200kgs
Choose to fix lift hook, loading weight 1000kgs~1500kgs
Main feature
1,The truck mainly used for high operation, for example electricity, telecommunications, street lighting, cable TV, garden, advertising, photography and so on.
2,The mainly valve and hydraulic cylinder all China famous brand or export brand.
3,Could operate on land or on the working bucket.



ISUZU Bucket Hydrulic Aerial Lift Work Trucks , Pickup Type Aerial Work Truck

Established in Sep. 2004,Chengli Special Automobile Co., Ltd is an important branch of CLW group with registered capital 100,000,000 RMB(14
millions US Dollars) and total capital 6,000,000,000(840 millions US Dollars).

ISUZU Bucket Hydrulic Aerial Lift Work Trucks , Pickup Type Aerial Work Truck
Overseas Market
Trucks from Chengli Special Automobile Co., Ltd have been sold to more than 29 provinces in China and more than 80 overseas countries and regions in
Asia, Africa, South America, middle east and so on, such as Russia, Mogolia, Philippine, Vietnam, Cambodia, Myanmar, Laos, Kazakhstan, uzbickstan,
Kyrghyzstan, Tanzania, Zambia, Nigeria, Austrilia, Chile, Bolivia, Ethiopia, Sudan, Malaysia, Congo, El Salvador, Iraq, New Zealand, Chile, Bolivia, Argentina
and so on.
