Heat Recovery Robust Serrated Microfin Tubes SA213 TP316 ASME
Heat Recovery Robust Serrated Microfin Tubes SA213 TP316 ASME
Heat Recovery Robust Serrated Microfin Tubes SA213 TP316 ASME
Heat Recovery Robust Serrated Microfin Tubes SA213 TP316 ASME
Heat Recovery Robust Serrated Microfin Tubes SA213 TP316 ASME
Heat Recovery Robust Serrated Microfin Tubes SA213 TP316 ASME
Specifications
Brand Name :
YUHONG
Model Number :
H Fin Tube
Certification :
ABS, DNV-GL, LR, BV, CCS, KR, ASME, TUV, SGS, BV, IEI, IBR, ISO9001, ISO 14001, ISO 18001
Place of Origin :
China , Korea
MOQ :
1 PC
Price :
1 - 10000 USD
Payment Terms :
L/C, T/T
Supply Ability :
10000 Tons/Month
Delivery Time :
5 - 90 Days
Packaging Details :
Ply-Wooden Case + Iron Frame
Material Grade :
TP316
Standard :
ASME SA213 , ASTM A213
Material :
Carbon steel, Alloy steel and Stainless steel
Type of base pipe :
Seamless steel pipe
Type of fins :
Single H / Double H Type
Application :
Widely used for boiler, heat exchanger, condenser, refrigerator, economizer and other parts of heat industry.
Description
SA213 TP316 ASME H Type Boiler Fin Tube Economizer For Waste Heat Energy Industrial
Product Specifications
Attribute Value
Material Grade TP316
Standard ASME SA213, ASTM A213
Material Carbon steel, Alloy steel and Stainless steel
Type of base pipe Seamless steel pipe
Type of fins Single H / Double H Type
Application Widely used for boiler, heat exchanger, condenser, refrigerator, economizer and other parts of heat industry
Product Overview
ASME SA213 TP316 H Type Boiler Fin Tube Economizer is an essential component in industrial systems designed to recover waste heat energy. These tubes are engineered for high efficiency and durability in economizers and other heat recovery systems.
Chemical Composition
Grade Cr Ni Mo C Mn Si P S
TP316 16.0-18.0% 10.0-14.0% 2.0-3.0% 0.08% max 2.0% max 1.0% max 0.045% max 0.030% max
Mechanical Properties
Grade Tensile Strength Yield Strength Elongation Hardness
TP316 ≥ 205 MPa (30 ksi) ≥ 515 MPa (75 ksi) ≥ 35% in 50 mm (2 inches) ≤ 90 HRB
Key Features
  • Material: Constructed from ASME SA213 TP316 stainless steel, known for excellent corrosion resistance and high-temperature strength
  • Seamless Construction: Provides uniform strength, reducing the risk of leaks and enhancing reliability
  • H Type Fin Design: Increases surface area significantly, optimizing heat transfer efficiency
  • Durability: Offers long service life with minimal maintenance due to robust material properties
Applications
  • Economizers: Recover residual heat from exhaust gases, preheating the feedwater and improving overall thermal efficiency
  • Heat Exchangers: Enhance energy recovery in power generation and industrial processes
  • Industrial Boilers: Increase efficiency and reduce fuel consumption in various industrial applications
