300W LED Explosion Proof Flood Light High Temperature T5 80°C Steel Mill Foundry Desert IP66 Die-Cast Aluminum ADC12
300W LED Explosion Proof Flood Light High Temperature T5 80°C Steel Mill Foundry Desert IP66 Die-Cast Aluminum ADC12
Specifications
Brand Name :
ECER
Model Number :
EPFL-300W-HIT
Place of Origin :
Guangdong, China
Certification :
ATEX II 2G Ex d IIC T5 Gb
MOQ :
10 pcs
Price :
Negotiable
Payment Terms :
T/T, Western Union
Supply Ability :
5000pcs/month
Delivery Time :
10-15 days or confirm
Packaging Details :
Box package+ bubble or as customized
Power :
300W
Luminous Flux :
33000lm
Efficacy :
110lm/W
Beam Angle :
90°
Color Temperature :
5000K
LED Chip :
Bridgelux SMD 3030
IP Rating :
IP66
Housing Material :
Die-Cast Aluminum ADC12 with High-Temp Coating
Operating Temperature :
-20°C to +80°C
Lifespan :
≥50,000 Hours L70
Warranty :
5 Years
Description

300W LED Explosion Proof Flood Light - High Temperature T5 80°C Steel Mill Foundry Desert

The EPFL-300W-HIT is a 300W LED explosion proof flood light delivering 33000lm luminous flux with 110lm/W efficiency. ATEX II 2G Ex d IIC T5 Gb certified with IP66 protection, this purpose-engineered floodlight features Die-Cast Aluminum ADC12 with High-Temp Coating for demanding classified area applications.

Key Features

  • 300W High-Efficiency Output - 33000lm total luminous flux at 110lm/W, replacing traditional HID fixtures with superior energy performance
  • ATEX II 2G Ex d IIC T5 Gb Certified - Full explosion-proof certification for Zone 1/Zone 2 gas and Zone 21/Zone 22 dust hazardous atmospheres
  • T5 High-Temperature Rating - Certified for continuous operation at 80°C ambient with high-temperature silicone gaskets and derated driver electronics for extended service life in extreme heat
  • IP66 Protection - Fully sealed against environmental ingress for reliable outdoor and industrial operation
  • High Transmittance Tempered Glass - Safety glass lens with excellent light transmission and impact resistance
  • Die-Cast Fin Heat Dissipation - Advanced thermal management ensuring consistent 300W performance and extended LED lifespan
  • 180° Adjustable Bracket - Flexible angle adjustment for precise positioning in any installation scenario
  • Universal Voltage Input - Compatible with global power distribution systems for simplified international deployment
  • 5-Year Warranty - Backed by ≥50,000 hours L70 rated lifespan and factory quality testing

Applications

Engineered for Steel mills, foundries, glass manufacturing, desert oil and gas installations, and high-ambient industrial zones:

  • Oil and gas exploration, production and refining facilities
  • Petrochemical processing and chemical manufacturing plants
  • Offshore platforms, FPSOs and marine terminals
  • Pharmaceutical and food processing classified zones
  • Mining, tunneling and underground hazardous spaces
  • Emergency and safety-critical lighting applications

Technical Specifications

Model NumberEPFL-300W-HIT
Power Consumption300W
Luminous Flux33000lm
Efficacy110lm/W
Beam Angle90°
Color Temperature5000K
LED ChipBridgelux SMD 3030
IP RatingIP66
Housing MaterialDie-Cast Aluminum ADC12 with High-Temp Coating
Operating Temperature-20°C to +80°C
CertificationATEX II 2G Ex d IIC T5 Gb
Lifespan≥50,000 Hours L70
Warranty5 Years

Each unit undergoes 100% factory testing of the explosion-proof enclosure integrity and photometric performance verification. Our 5-year warranty reflects confidence in the long-term reliability of the EPFL-300W-HIT design.

For bulk orders, OEM customization, or technical inquiries, please contact our sales team.
