160μm Heavy-Gauge Red CPE Base Film with Fade-Resistant Color and Puncture-Proof Performance for Industrial Applications
160μm Heavy-Gauge Red CPE Base Film with Fade-Resistant Color and Puncture-Proof Performance for Industrial Applications
160μm Heavy-Gauge Red CPE Base Film with Fade-Resistant Color and Puncture-Proof Performance for Industrial Applications
160μm Heavy-Gauge Red CPE Base Film with Fade-Resistant Color and Puncture-Proof Performance for Industrial Applications
160μm Heavy-Gauge Red CPE Base Film with Fade-Resistant Color and Puncture-Proof Performance for Industrial Applications
160μm Heavy-Gauge Red CPE Base Film with Fade-Resistant Color and Puncture-Proof Performance for Industrial Applications
Specifications
Place of Origin :
China
Color :
Red
Web Width :
Up to 2600mm
Brand Name :
HSF
Packaging Details :
Export Standard
Delivery Time :
10 working days
Surface Finish :
double-sided glossy, one side matte one side glossy, or double-sided matte.
Model Number :
CPE120R
Payment Terms :
T/T
Supply Ability :
50 days per day
Material :
LDPE or blended PE
MOQ :
1000kg
Thickness :
30μm~300μm
Description
160μm Heavy-Gauge Red CPE Base Film
This premium 160μm red cast polyethylene base film is engineered for ultra-heavy-gauge performance applications. Manufactured using advanced precision cast extrusion technology, it delivers exceptional durability, uniform thickness, and superior mechanical properties.
Production Process
Crafted from high-purity LDPE resin homogenously blended with high-concentration, light-fast red masterbatch, this film undergoes precise temperature-calibrated extrusion (175-195℃) for complete fusion. The material is extruded through a high-precision flat die and cast onto mirror-polished cooling rollers for rapid, uniform solidification. Post-extrusion processes include strict thickness calibration, constant tension control, static neutralization, and precision edge trimming, resulting in tight, defect-free rolls with consistent 160μm gauge.
Key Features
  • Strict thickness tolerance of ±4% for uniform density and performance
  • Vibrant, fade-resistant red color maintains vividness through high-temperature processing
  • Superior tensile strength and excellent tear resistance
  • Robust puncture-proof performance for heavy-duty applications
  • Ultra-smooth surface ensures seamless lamination and coating compatibility
  • Optional anti-static treatment available for specialized industrial needs
Product Advantages
The ultra-thick 160μm gauge provides exceptional puncture-proof and load-bearing capabilities, minimizing damage during handling and converting operations. The vivid red color enables quick visual identification in high-volume production lines, enhancing sorting efficiency. The smooth surface improves lamination and coating performance while reducing conversion waste. With exceptional batch-to-batch consistency, this film combines heavy-duty durability with cost-effectiveness.
160μm Heavy-Gauge Red CPE Base Film with Fade-Resistant Color and Puncture-Proof Performance for Industrial Applications 160μm Heavy-Gauge Red CPE Base Film with Fade-Resistant Color and Puncture-Proof Performance for Industrial Applications
Application Environment
Optimized for heavy-duty industrial scenarios including industrial packaging, heavy-duty surface protection, automotive component wrapping, and mechanical part shielding. The puncture-proof structure and smooth surface make it ideal for high-demand converting processes. Performs reliably in dry, normal-temperature environments and moderate low-temperature storage (≥-10℃). Optional anti-static treatment makes it suitable for electronics and clean-room related packaging applications.
Quality Performance Specifications
Test Item Unit Industry Standard Requirement Our Product Standard Actual Test Result Qualification
Total Thickness of Base Film μm 160±16 160±9 159.2 (LDPE 47.6/LLDPE 111.6) Qualified
Redness Uniformity - No obvious color difference, uniform coloring No color difference, uniform dispersion No color difference, uniform masterbatch dispersion Qualified
Light Shielding Rate % ≥95.0 ≥97.0 97.6 Qualified
Tensile Strength (Longitudinal/Transverse) MPa ≥28/≥26 ≥30/≥28 30.8/28.9 Qualified
Elongation at Break (Longitudinal/Transverse) % ≥370/≥350 ≥390/≥370 398/379 Qualified
Heat Sealing Strength N/15mm ≥16.0 ≥18.0 18.7 Qualified
Surface Tension mN/m ≥36 ≥38 40.1 Qualified
Tear Resistance (Longitudinal/Transverse) N ≥23/≥21 ≥25/≥23 25.7/23.9 Qualified
Moisture Barrier Performance g/(m²·24h) ≤4.8 ≤4.2 4.0 Qualified
Oil Resistance - No obvious swelling, discoloration or deformation No swelling, no discoloration, no adhesion No swelling, no discoloration, no adhesion Qualified
Hardness (Shore D) HD 60±5 60±3 59.8 Qualified
Weather Resistance - No obvious fading, cracking or discoloration No fading, no cracking, no deformation No fading, no cracking, no deformation Qualified
Environmental Protection Performance - Complies with GB 4806.7-2016 Complies with GB 4806.7-2016 Complies with GB 4806.7-2016 Qualified
