ALN‑FS400 Carding & Impurity‑Removing Machine
ALN‑FS400 Carding & Impurity‑Removing Machine
ALN‑FS400 Carding & Impurity‑Removing Machine
ALN‑FS400 Carding & Impurity‑Removing Machine
ALN‑FS400 Carding & Impurity‑Removing Machine
ALN‑FS400 Carding & Impurity‑Removing Machine
Specifications
Model Number :
FS400
Brand Name :
ALN
Payment Terms :
T/T,D/P,D/A,L/C
Delivery Time :
10-15work days
Description

Product Name: ALN‑FS400 Fiber Carding Machine

Equipment Purpose: Fiber disintegration and impurity discharge, providing effective preparation and material transfer for subsequent carding processes.

Overall Dimension: 1490 × 1750 × 1350 mm

Power Supply: 380V / 50Hz

Power: Installed power: 11 kW (rated power); Actual operating power: 6.6 kW

Capacity: 160‑360 kg/h

Configuration Requirements: Variable‑frequency motor, automatic fire suppression system, automatic brake

Technical Features & Key Points:

  1. Adopt high‑strength rollers with quenching treatment.
  2. Pin‑type opening roller, avoids fiber damage and keeps low short‑fiber content.
  3. Integral high‑strength steel plate frame for high stability.
  4. Equipped with automatic brake and automatic fire suppression system. Detects hazards via smoke, temperature and flame sensors. In case of fire emergency, the running beater will brake automatically, and high‑pressure ultra‑fine dry powder will be sprayed into equipment chamber for fire extinguishing.
  5. Double‑roller design with special card clothing for cotton & bast‑fiber disintegration, fitted with impurity separation blades.
