High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
Specifications
Brand Name :
FURONG
Model Number :
Air Blown Cable
Certification :
ROHS
Place of Origin :
Guangdong China
MOQ :
10KM
Price :
Negotiation
Payment Terms :
T/T, L/C, Western Union
Delivery Time :
2000KM per Day
Packaging Details :
4-5km/wooden drum
CORES :
As per buyer's request
Strength member :
steel wire
Armoured :
Steel tape
Jacket :
PE
OD :
As per buyer's request
Description

High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH

Specifications:

TYPE A

Temperature range

℃

-20℃~+60℃

Outer diameter

±0.1mm

3.3

Nominal weight

g/m

9.5

Min. Bending Radius

Dynamic

mm

20D

Static

mm

10D

Max. Tensile Strength

Short term

N

200

Long term

N

80

Max. Crush Resistance

Short term

N/100m㎡

1000

Long term

N/100m㎡

300

Type B

Temperature range

℃

-30℃~+60℃

Outer diameter

±0.1mm

2.0

Nominal weight

g/m

3.1

Min. Bending Radius

Dynamic

mm

20D

Static

mm

10D

Max. Tensile Strength

Short term

N

70

Long term

N

25

Max. Crush Resistance

Short term

N/100m㎡

500

Long term

N/100m㎡

150

Description:

Be mainly used in access network and metropolitan network

The cable can be installed either in new tiny conduit or existing conduit by air-blowing technology instead

of excavating the road. This way can not only reduces the use of conduit, but also meets the need of rapid

network expansion.

An effective solution to FTTH application

Characteristics

Small outer diameter; light weight and high fiber density

Easy to air-blowing and laying

Be adaptable to different temperature range

Good performance in crush and bending resistance

Applications:

Air-blowing in the conduit

Access to FTTH application

model

Fiber

count

Cable OD

Loose tube

count

Nominal

weight

Max. Tensile strength

Max crush resistance

Short term

Long term

Short term

Long term

GCYFTY

24

6.0±0.3

6

33

200

100

450

200

GCYFTY

36

6.0±0.3

6

33

200

100

450

200

GCYFTY

48

6.0±0.3

6

33

200

100

450

200

GCYFTY

60

6.0±0.3

6

34

200

100

450

200

GCYFTY

72

6.0±0.3

6

34

200

100

450

200

GCYFTY

96

6.7±0.3

8

41

250

150

450

200

GCYFTY

144

9.5±0.3

12

72

250

150

450

200

Our advantage


1. Professional cable manufacturer.
2. We provide good quality Fiber Optic cable with manufacture competitive price
3. Best delivery time
4. OEM service provide,Your own logo and own design are welcomed.
5. Long distance factory review by video talk
6. Can be customized production of fiber optic cable
7. 30 years cable service life , even 60 years cable service life.

High Density 24 - 144 Core Air Blown Fiber Optic Cable For Outdoor FTTH
