100m High Speed Fiber Optical 40G QSFP+ Active Optical Cable (AOC), LSZH Jacket

The QSFP+ AOC cables are composed of QSFP+ transceivers in both ends and OM3 multimode fiber cable in different cable length from 1 to 100 meters. They offer 4 independent data transmission channels and 4 data receiving channels via the multimode fibers. An aggregate data rate of 40 Gbps can be achieved by this product. The QSFP+ AOC is one kind of parallel transceiver which provides increased port density and total system cost savings.

Features

1. Compliant to industrial standard QSFP+ MSA SFF-8436;
2. Compliant to the IEEE802.3ba(40GBASE-SR4);
3. High speed/high density: support up to 4×10 Gb/s bi-directional operation;
4. Maximum 1.5W operation power;
5. Reliable VCSEL and PIN photonic devices;
6. Excellent high-speed signal integrity;
7. Low weight for high-port-count architectures;
8. Small cable bend radius;
9. Available in lengths of 1 to 100m;
10. Operating case temperature: 0 to 70℃;
11. RoHS-6 compliant.

Applications

(1) 40 Gigabit Ethernet links;
(2) Fiber Channel over Ethernet;
(3) Data storage and communication industry;
(4) Switches, servers,routers and HBA;
(5) Enterprise network;
(6) SAN (Storage area networks);
(7) Data center cabling infrastructure;
(8) High density connections between networking equipment.

Technical Parameter

Receiver

Measured Condition: Channel Data Rate 25.78125Gbps, VRCCR=3.3V, PRBS31, Case Operating Temperature 0~70℃.
