1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch
1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch
1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch
1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch
1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch
1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch
1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch
1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch
Specifications
Brand Name :
Hangalaxy
Model Number :
HGYN-0878
Certification :
CE, UL, SGS, ROHS, ISO9001
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
15000PCS Monthly
Delivery Time :
7 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Interfaces :
1 x HDMI Type A Female (Black)
Impedance :
100 Ώ
Max. Distance :
1.8m / 4K@60Hz (4:4:4)
Max. Data Rate :
18Gpbs (6 Gbps Per Lane)
Max. Pixel Clock :
Ma600 MHz
Color :
Black
Housing :
Metal
Weight :
0.48 kg ( 1.06 lb )
Description

1×4 HDMI2.0 HDR Splitter 4Kx2K@60Hz

Hangalaxy this kind of HDMI Switch with Optica/Coaxial/3.5mm Audio Out, 4 Port 4 x 1 Switcher Selector with IR Wireless Remote Control, 4K@60Hz, HDMI2.0 HDCP 1.4, Support DTS-HD/Dolby-TrueHD/DTS/Dolby-AC3/ DSD. This kind of True 4K HDMI Splitter from Hanglaxy Company is the perfect solution for anyone who needs to send one source of digital high definition video to four displays at the same time. It supports all HDMIenabled equipment, such as DVD players, satellite set- top boxes and all HDMI monitors, displays, projectors, or TVs. The 4K HDMI Splitter is HDMI 2.0 compliant, 4K at 60Hz (4:4:4), and supports multiple streaming audio, making it effective for use with all HDMI displays in home theater applications, as well as in corporate, educational and commercial settings. HDMI splitter distributes 1 HDMI source to 4 HDMI displays simultaneously. Apply for STB, DVD, Media Player, Laptop, D-VHS and other HD-Player devices. It's compatible with HDMI 3D and 4Kx2K.

Key Characteristic

1. Distribute 1 HDMI source to 4 HDMI displays;
2. Support ultra HD resolution 4K×2K@60Hz;
3. Support HDMI 3D;
4. Support YUV 4:4:4;
5. Support HDR;
6. HDMI 2.0 and HDCP2.2 compliant;
7. Low power consumption;
8. Support configures the video resolution automatically according to the capabilities of each connected monitor, allows simultaneous mixed 4K and 1080p display outputs;
9. Plug and play.

Specification

Video Input
Interfaces 1 x HDMI Type A Female (Black)
Impedance 100Ώ
Max. Distance 1.8m / 4K@60Hz (4:4:4)
Video Output
Interfaces 4 x HDMI Type A Female (Black)
Impedance 100Ώ
Max. Distance 1.8m / 4K@60Hz (4:4:4)
Video
Max. Data Rate 18Gpbs (6 Gbps Per Lane)
Max. Pixel Clock 600 MHz
Compliance HDMI (3D, Deep Color, 4K); HDCP Compatible
Max. Resolution Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

Audio
Input 1 x HDMI Type A Female (Black)
Output 4 x HDMI Type A Female (Black)
Connectors
Power 1 x DC Jack
Power Consumption DC5V:4.84W:23BTU
Physical Properties
Housing Metal
Weight 0.48 kg ( 1.06 lb )
Dimensions (L x W x H) 20.00 x 8.00 x 2.50cm (7.87 x 3.15 x 0.98 in.)

1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch

Ideal Application

1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch

Hangalaxy Exhibition Activities

1×4 HDMI2.0 4K 8K HDMI Splitter Extenders / 60Hz 2Kx4k Hdr Hdmi Switch

Package


UHD 1x4 HDMI Splitter: 1PC
5V2A DC Power adapter: 1PC
Operation Manual: 1PC

Note

For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
