Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing
Specifications
Brand Name :
Hangalaxy
Model Number :
HGYN-0879
Certification :
CE, UL, SGS, ROHS, ISO9001
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
15000PCS Monthly
Delivery Time :
7 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Interfaces :
1 x HDMI Type A Female (Black)
Impedance :
100 Ώ
Max. Distance :
1.8m / 4K@60Hz (4:4:4)
Max. Data Rate :
18Gpbs (6 Gbps Per Lane)
Max. Pixel Clock :
Ma600 MHz
Color :
Black
Housing :
Metal
Weight :
0.48 kg ( 1.06 lb )
Description

HDMI 2.0 4K 1 x 4 HDMI Distribution Amplifier Splitter Up to 4 Outputs

Hangalaxy this kind of HDMI Switch with Optica/Coaxial/3.5mm Audio Out, 4 Port 4 x 1 Switcher Selector with IR Wireless Remote Control, 4K@60Hz, HDMI2.0 HDCP 1.4, Support DTS-HD/Dolby-TrueHD/DTS/Dolby-AC3/ DSD. This 1x4 HDMI splitter distributes 1 HDMI source to 4 HDMI displays simultaneously. Apply for STB, DVD, Media Player, Laptop, D-VHS and other HD-Player devices. It's compatible with HDMI 3D and 4Kx2K.

Key Characteristic

1. Connects up to 4 HDMI displays at the same time from a digital video source.
2. Support up to 3D, 4K 30Hz 4:4:4, 12-Bit deep color.
3. Built in EDID learning/integration function.
4. Support LPCM 7.1,Dolby TrueHD,DTS-HD Master Audio.
5. Bandwidth: 25~340 Mhz.
6. HDMI 1.4a compliance, HDCP 1.4 complaint.
7. DVI 1.0 compliance.

Application

Support configures the video resolution automatically according to the capabilities of each connected monitor, allows simultaneous mixed 4K and 1080p display outputs.

Specification

Video Input
Interfaces 1 x HDMI Type A Female (Black)
Impedance 100Ώ
Max. Distance 1.8m / 4K@60Hz (4:4:4)
Video Output
Interfaces 4 x HDMI Type A Female (Black)
Impedance 100Ώ
Max. Distance 1.8m / 4K@60Hz (4:4:4)
Video
Max. Data Rate 18Gpbs (6 Gbps Per Lane)
Max. Pixel Clock 600 MHz
Compliance HDMI (3D, Deep Color, 4K); HDCP Compatible
Max. Resolution Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)

Audio
Input 1 x HDMI Type A Female (Black)
Output 4 x HDMI Type A Female (Black)
Connectors
Power 1 x DC Jack
Power Consumption DC5V:4.84W:23BTU
Physical Properties
Housing Metal
Weight 0.48 kg ( 1.06 lb )
Dimensions (L x W x H) 20.00 x 8.00 x 2.50cm (7.87 x 3.15 x 0.98 in.)

Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing

Ideal Application

Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing

Hangalaxy Exhibition Activities

Home HDMI 2.0 4K Hdmi Distribution Amplifier 1x4 Up To 4 Outputs Metal Housing

Package


UHD 1x4 HDMI Splitter: 1PC
5V2A DC Power adapter: 1PC
Operation Manual: 1PC

Note

For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
