Singlemode LC APC Fiber Reflector For FTTH Network Green ABS Plastic
Singlemode LC APC Fiber Reflector For FTTH Network Green ABS Plastic
Singlemode LC APC Fiber Reflector For FTTH Network Green ABS Plastic
Singlemode LC APC Fiber Reflector For FTTH Network Green ABS Plastic
Specifications
Brand Name :
Hangalaxy
Model Number :
HGYN-001
Certification :
ISO9001, CE, RohS, SGS, UL
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability :
25000PCS Monthly
Delivery Time :
7-10 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Connector :
LC
Polish Type :
APC
Wavelength :
1625nm
Color :
Green
Material :
ABS Plastic
Pass Band :
1.0dB
PDL :
0.4dB
Max Power Optical Handling :
27dBm
Description

1625nm Singlemode LC APC Fiber Optic FBG Reflector for FTTH Network

The FBG reflector is a standard SC/LC type connector structure, which package a special FBG in the ceramic ferrule. The fiber bragg grating reflector is a low-cost specific band reflector mounted on the optical network unit (ONU) side. It can reflect light pulses (1650 +/- 5nm) from the OTDR on the fiber line terminal (OLT) side nearly 100%, while the working bands of the passive optical network (PON) are transmitted normally. The OTDR can determine whether the fiber line is normal by detecting the signal reflected by the fiber grating reflector. When the reflected signal is lower than the normal value, the line loss is too large; when the reflection value is 0, the optical fiber line is broken. Therefore, we can maintain the fiber line in time by the real-time monitoring of the fiber line.

Characteristics

(1) High stability and reliability.
(2) Remote real-time detection.
(3) Low insertion loss.
(4) Easy connection for adapter structure.
(5) Compliant with Telcordia GR-326-CORE, Telcordia GR-1221-CORE.
(6) Compliant with RoHS.

Application


1. Detection and maintenance of Passive Optical Network lines (applied to FTTx).

Specification

Item Parameter Specification Unit Remarks
1 Wavelength Range Pass Band 1260~1625 nm -
Reflect Band 1644.5~1655.5 nm

2

Pass Band

IL

 ≤1.0 dB @1260~1360
≤1.0 dB @1460~1600
≤1.5 dB @1600~1625

ORL

 >35 dB @1260~1580
>30 dB @1580~1620
>20 dB @1620~1625
3 Reflect Band IL >21 dB @1644.5~1655.5
ORL ≤1.0 dB @1644.5~1655.5
4 PDL ≤0.4 dB @1260~1600
5 Ripple ≤0.6 dB @1644.5~1655.5
6 TDL ≤0.5 dB @1260~1600
7 Max Power Optical Handling 27 dBm -
8 Plug Time >500 Times -
9 Connector Mode LC/APC - -

Work & Storage Conditions

Parameter Specification Unit
Working Temp. -25 ~ +65 ℃
Working Humidity 5 ~ 95 %RH
Storage Temp. -40 ~ +85 ℃
Working Humidity 5 ~ 95 %RH

Singlemode LC APC Fiber Reflector For FTTH Network Green ABS Plastic

Hangalaxy FBG Optical Reflector Workshop

Singlemode LC APC Fiber Reflector For FTTH Network Green ABS Plastic

Singlemode LC APC Fiber Reflector For FTTH Network Green ABS Plastic

OEM/ODM Service


If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.

Packing


(1) According to Stardard Export Packing;
(2) Carton box, wooden box, wooden pallet.

Shipping


(1) International express such as UPS, TNT, DHL, etc;
(2) Internatioal air: CA, AA, EA, etc;
(3) By sea.
