10G SFP+ 1550nm 40km Fiber Transceiver Module For 10G Ethernet
10G SFP+ 1550nm 40km Fiber Transceiver Module For 10G Ethernet
10G SFP+ 1550nm 40km Fiber Transceiver Module For 10G Ethernet
10G SFP+ 1550nm 40km Fiber Transceiver Module For 10G Ethernet
10G SFP+ 1550nm 40km Fiber Transceiver Module For 10G Ethernet
10G SFP+ 1550nm 40km Fiber Transceiver Module For 10G Ethernet
Specifications
Brand Name :
Optowix
Model Number :
MF3H-15TE
Certification :
CE
Place of Origin :
China
MOQ :
10pcs
Payment Terms :
T/T
Supply Ability :
10Kpcs
Delivery Time :
5-8 working days
Packaging Details :
ESD plastic case
Product Name :
10G SFP+ 1550nm 40km Module
Optowix PN :
MF3H-15TE
SpeedRate :
10G
Distrance :
40km
Interface :
LC duplex
Description

10G SFP+ 1550nm 40km Module Optical Transceiver Module

Features

· Support data rate up to 11.3Gb/s

· Temperature-Stabilized EML Transmitter and PIN Receiver

· Hot-Pluggable SFP Footprint and Duplex LC Connector

· Up to 40km reach for G.652 SMF

· Temperature Range:

Industrial:-40°C ~+85°C

Applications

· 10G Ethernet

· 10GBASE-ER at 10.31Gbps

· 10GBASE-EW at 9.95Gbps

· OTU2/2e

· 10G FC

· Other Optical Links

Standards

· SFF-8431

· SFF-8432

· SFF-8472

· IEEE802.3ae

Ordering information

Part Number Product Description
MF3H-15TE

SFP+, 10G, 1550nm, 40km, -40ºC ~ 85ºC

Absolute Maximum Ratings

Parameter Symbol Min Typ Max Unit
Storage Temperature Range Ts -40 85 °C
Maximum Supply Voltage VCC -0.5 3.6 V
Relative Humidity RH 95

%

Recommended Operating Conditions

Parameter Symbol Min Typ Max Unit Note
Operating Case Temperature Top -40 85 °C
Power Supply Voltage VCC 3.13 3.3 3.47 V
Bit Rate BR 10.3125 11.3 Gbps
Transmission Distance TD 40 km
Coupled fiber Single mode fiber 9/125um SMF
