IP67 Waterproof Stainless Steel Fiber Optic Connectors
IP67 Waterproof Stainless Steel Fiber Optic Connectors
IP67 Waterproof Stainless Steel Fiber Optic Connectors
IP67 Waterproof Stainless Steel Fiber Optic Connectors
IP67 Waterproof Stainless Steel Fiber Optic Connectors
IP67 Waterproof Stainless Steel Fiber Optic Connectors
IP67 Waterproof Stainless Steel Fiber Optic Connectors
IP67 Waterproof Stainless Steel Fiber Optic Connectors
Specifications
Brand Name :
Fujioptics
Model Number :
FJ-J599
Certification :
ROHS,CE , ISO9001
Place of Origin :
MADE IN CHINA
MOQ :
100pcs
Price :
Negotiable
Payment Terms :
L/C, , T/T
Supply Ability :
10000pcs
Delivery Time :
5-7 working days
Packaging Details :
PE Bag and Carton
Description

J599A8 series Optical Connector/Stainless Steel Metal Connector/IP67 Optical Fiber Waterproof Patchcord

Introduction:

Different shell materials and plating, applicable for different environments

Five-key way orientation, blind mating, anti mis-mating function

Tri-start thread quick coupling with anti-loose mechanism

Ceramic ferrule and sleeve to achieve precise mating

Various termination alternative types

Adapter (hermetic type optical) without optical cable bondage

Features and Application:

●Industrial standard:Q/21EJ1305 connector size comply with GJB599A standard.

●(MIL-DTL-38999)Ⅲ,performance meet with ARINC801 standard.

●Applied in aviation, electronics, ships and other systems for multiplexed optical communication

● outer casing can choose different materials and coatings to adapt to different environmental requirements

● five key location, there are blind mating and error proofing interpolation function

● three Screw thread quick connect, and with anti-release mechanism

● ceramic pin and sleeve contacts to achieve precision docking

● There are many variations of the optional rear

● With adapter socket (optional hermetic seal) form, get rid of the shackles of cable

Connector Parameter

● Insertion loss: ≤0.6dB •

● Working temperature: -55 ℃ ~ + 85 ℃

● Vibration: 10Hz ~ 2000Hz, power spectral density 0.4G2 / Hz

● Shock: 2940 m / s2, duration of 3ms, the rate of change of velocity 2.96m / s

● Mechanical life: 500 times

● tensile strength: ≥68N (2mm contacts jumper)

● Gas tightness (applies to airtight adapter socket): gas leakage ≤1 * 10-9 Pa.m3 / S and external pressure is 1 atm

● ≥1000h (stainless steel, aluminum, cadmium plated ≥48h (aluminum nickel-plated)
